SOMFY IO Anleitung Seite 18

EN
Impossible to change the
temperature
I want to change the
thermostatic valve from one
radiator to another
I want to reinitialise the ther-
mostatic valve
I want to pair my thermostatic
valve with my box again.
6. TECHNICAL DATA
Dimensions
Weight
Power supply
Operating mode
Pollution degree
Index protection rating
Radio frequency
Frequency bands used and maximum power
Protocol
Design
Compatibility
Ambient operating temperature
Measured Temperature (air and water)
Accuracy
Adjustment range
Increment
18
The thermostatic valve may have been locked via TaHoma.
Press the + and - buttons simultaneously for 10 seconds to
unlock it or access your TaHoma settings to unlock the head.
Remove the batteries from the product then screw the
thermostatic valve onto the new radiator and reinsert the
batteries. Press the + button for 3 seconds to start the end
limit search again.
Press the + and - buttons simultaneously for 12 seconds and
release when icon 9 is displayed. If the reinitialisation was
successful, the thermostatic valve displays "OK".
Press the + and - buttons simultaneously for 7 seconds
and release when icon 8 is displayed. If the io reset was
successful, the thermostatic valve displays "OK".Then start the
pairing procedure with your box again.
87 x 55 x 48 mm (L x W x H)
160g
2 alkaline AA batteries - 2-year battery life
Type 1
Pollution 2
IP20
868.25 MHz - 868.95 MHz - 869.85 MHz
868.000 MHz - 868.600 MHz e.r.p. < 25 mW
868.700 MHz - 869.200 MHz e.r.p. < 25 mW
869.700 MHz - 870.000 MHz e.r.p. < 25 mW
io Homecontrol – 2 way
2 + and – buttons
LED screen
Native M30 x 1.5 mm
3 adapters: M28x1.5, RA, RAV
0°C – 50°C
0°C to 90°C
+/- 1°C
5°C to 26°C
0.5°C
Copyright 2019 SOMFY ACTIVITES SA, Société Anonyme. All rights reserved.
©
Thermostatic valve io
