Maintenance And Care - STEINEL HF 360-2 COM1 BT IPD Bedienungsanleitung

Presentation mode
If input S is used in fully automatic mode
with load activated, the sensor will
activate presentation mode. The load
remains switched OFF as long as move-
ment is being detected. As soon as move-
ment is no longer being detected and the
stay-ON time has elapsed, the sensor
returns to normal sensor mode.
Button input
Tells the sensor how to interpret incoming
signal S. Assigning external buttons allows
you to operate the detector as a semi-
automatic unit and override it manually
at any time. SOUND or SOUND / OFF
describes the behaviour after actuating
the button. In the ON – OFF setting, the
light can be switched ON and OFF man-
ually at any time. In the SOUND setting,
light can no longer be switched OFF
manually. The stay-ON time starts from
the beginning again each time the switch
is pressed.
IQ mode
The stay-ON time is self-learning and
adjusts dynamically to user behaviour.
The optimum time cycle is determined
by means of a learning algorithm. The
shortest time is 5 minutes, the longest
time 20 minutes.
Pulse mode
The pulse function activates the output
for 2 seconds (e.g. for staircase lighting
time switches). The sensor will then be in
a dead time for 8 seconds.
Smart Remote app
To read off the sensor via smartphone or
tablet, you must download the STEINEL
Smart Remote app from your app store.
You will need a Bluetooth-capable smart-
phone or tablet.
Android
iOS
LED function
Initialisation: LED flashes blue.
Normal mode: LED OFF
Bluetooth connection active:
LED is flashes slowly in blue.
Test mode, movement:
LED permanently lights up green
Movement test mode no movement:
LED permanently lights up red
HF 360-2
Set detection reach. (Fig� 6�1, Fig� 6�2,
Fig� 6�3)
7� Maintenance and care
The product requires no maintenance.
The sensor can be cleaned with a damp
cloth (without detergents) if dirty.
- 20 -
