Programming the Operator
14
Control elements
The controls for programming the door operator
are protected by a transparent cover. The
transparent cover can be opened with a
screwdriver.
After the operator has been programmed, the
transparent cover must be closed again.
A. Numerical display shows the menu stage as well
as the selected value.
a. Point display, lights up to indicate "ready for
operation" and flashes on the hand transmitter
code learning completion.
B. Button during the setting / adjustment phase
serves as an "up" button and outside the menu
as a start button.
C. Button during the setting / adjustment phase
serves as a "down" button.
D. Button is used to call up the setting /
adjustment menu, to change the menu stages
and to store the settings.
Programming the control unit is menu-driven.
Pressing button calls up the menu guide. The
numbers displayed indicate the menu stage. After
approx. 2 seconds the display flashes and the
setting can be altered via buttons
The selected setting is stored with button
the programme jumps automatically to the next
menu stage. By repeatedly pressing button
menu stages can be skipped. To quit the menu,
press button until "0" is shown again. Outside
the menu, button can be used to generate a
start impulse.
Before programming
- Allow door to engage into the carriage.
- Plug in at the mains. Point display (a) lights up.
- Make sure that the aerial is correctly positioned
(see figure 13).
- Observe the hand transmitter instructions.
15
Menu stage 1: Programming the start
function for the hand transmitter
Briefly press button .
"1" is displayed.
As soon as the display flashes, press and keep
pressed for approx. 1 second the button of the
hand transmitter, with which you later wish to start
the operator.
As soon as the code has been read, the red point
display (a) flashes five times before quitting.
Further hand transmitters (up to a maximum of 10)
can be programmed.
16
Menu stage 2: Programming the light
function for the hand transmitter
Press button .
"2" appears in the display.
Note: If no 4-minute light is to be programmed,
repress button . The display shows "0" -
programming is completed.
Press the second button on the hand transmitter,
with which the 4-minute light is to be switched on.
As soon as the code has been read, the red point
display (a) flashes five times before quitting.
After the code has been learned, briefly press
button .
"0" appears indicating that you have come to the
end of the menu.
Deletig all the hand transmitters programmed for
Retain these installation, operating and maintenance instructions for the full duration of the operator's service life!
the operator:
Plug in the operator's mains plug and whilst button
pressed.
17
Menu stage 3: Setting / adjusting the top
end of-travel position
Keep button
appears in the display.
Wait a short while until the 3 starts flashing.
Press button
travel in the OPEN direction as long as the button
is pressed. The position can be altered to the
CLOSE direction via button
Once the desired OPEN end-of-travel position has
been reached, press button
stores the OPEN end-of-travel position and "4"
appears in the display.
18
Menu stage 4: Setting / adjusting the
bottom end-of-travel position
Wait a short while until "4" starts flashing.
Press button
travel in the CLOSE direction as long as the button
is pressed. The position can be altered to the
OPEN direction via button
Once the desired CLOSE end-of-travel position
has been reached, press button
stores the CLOSE end-of-travel position and "5"
appears in the display.
and .
Press button
and
18a
Force-learning cycle
Attention: During this opening and closing cycle
the operator learns the force required to open and
close the door. A force limit does not apply! The
cycles must not be interrupted. During these cycles
"0" appears in the display.
- Press button
open until the top end-of-travel position has
been reached.
- Now press button
the door to close until the bottom end-of-travel
position has been reached.
- After approx. 2 seconds "0" goes out.
19
Menu stage 5: The opening force limit
If you have previously quit the setting menu, press
button for 3 seconds until "3" appears. Then
press button
After approx. 2 seconds the display flashes
showing the set value of the opening force limit.
The force limit setting can be increased or
decreased via buttons
After setting the value, press button
The display shows "6".
20
Menu stage 6: The closing force limit
After approx. 2 seconds the display starts flashing
and the set value for the closing force limit is
displayed.
The force limit setting can be increased or
decreased via buttons
After setting the value, press button
appears in the display.
Finally, check the force settings and, if necessary,
repeat the setting procedure.
The maximum force at the main closing edge must
not exceed 150N!
Caution! If the force setting is too high, persons
may be placed at risk of injury.
The factory setting is 4!
pressed for 3 seconds. Number 3
. The operator causes the door to
.
. The operator
. The operator causes the door to
.
. The operator
twice until "0" appears.
. The operator causes the door to
again. The operator causes
twice until "5" appears.
and .
.
and .
. "0"
21 21
21
Checking the force limit facility
- Place an obstruction (e. g. operator's cardboard
box) underneath the door's cosing edge.
- Starting from the OPEN end-of-travel position,
actuate the door to close.
- The door travels towards the obstruction, stops
and travels back to the top end-of-travel
position.
- The point display (a) must switch off for approx.
1 second. Then the operator functions as normal
again.
If the door springs have been changed or altered,
then the force learning cycle must be repeated:
Proceed to menu stage 5 and keep button
pressed for 3 seconds. "0" appears in the display.
Then complete the force learning cycle as
explained under point 18a.
Special settings
Menu stage 7: Light phases
Press button for 3 seconds.
"3" appears in the display.
Press button several times until menu stage 6
is shown.
Keep button pressed again for 3 seconds until
"7" appears in the display.
Menu- Light phase
value
0 60 s
1 90 s
2 120 s
3 240 s
4 0 s
5 90 s
6 240 s
7 0 s
8 90 s
9 240 s
If the warning phase is set, the light flashes before
the door starts to move and during the actual travel
cycle. The factory setting is 1.
Menu stage 8: "Soft" start and "soft" stop
("soft" runs)
Press button . "8" appears in the display.
Menu- Start Stop Start
value Open Open Close
0 0 0 0
1 15 0 15
2 0 15 0
3 15 15 15
4 25 45 25
5 15 15 15
6 15 15 15
7 35 35 35
8 60 15 15
9 soft run only
These values correspond to the "soft" runs
measured in cm at the carriage.
Important note:
The factory setting of 4 must be adhered to. The
"soft" runs may only be altered on the express
permission of the door manufacturer. Press button
. "0" appears in the display.
GB
Warning
phase
-
-
-
-
3 s
3 s
3 s
10 s
10 s
10 s
Stop
Close
0
0
60
35
45
60
15
50
85
