Overview toolbox
EN
1
1
28
2
1
6
8
7
9
1
3
2
2
5
4
2
3
10
8
9
12
11
Bottom side
1. Fusion device
2. Ratchet, hexagon socket allen key
and tempil sticks
3
4
3. Holder for fusion device
4. Heating elements d40
5
5. Heating elements 1/2"-1", d16-d32
6. Heating elements d50
7. Fitting holder d50
8. Fitting holder 1/2"-2", d16-32
9. Fitting holder d40, Timer and spare
screws for heating elements
Unlock separation
Top side
1. Hole saw 40+50
2. Screw driver
3. Deburring tool
6
4. Centering aid inner pipe 1/2"-1",
7
5. Centering aid jacket pipe + hole saw
6. Centering aid inner pipe 40+50 hole
7. Adapter guiding sleeve 40+50
8. Adapter guiding sleeve 1/2"-1",
9. Marker
10. Hole saw d40
11. Base plate
12. Drilling adapter
d16-d32 + hole saw 1/2"-1",
d16-d32
jacket pipe 1/2"-1", d16-d32
saw d50
d16-d32
