Betriebsanleitung Instruction manual Notice d'instructions Pulscon LTC50, LTC51, LTC57 4-wire, 4 mA ... 20 mA HART ATEX: II 1/2G Ex d [ia] IIC T6-T1 Ga/Gb II 1/2D Ex ta IIIC Txx°C Da/Db SI01136O-D DE – Sicherheitshinweise für elektrische Betriebsmittel für explosionsgefährdete Bereiche, siehe Seite 7 EN –...
Seite 2
Pokud nemáte možnost přečíst si tento návod, můžete si u nás objednat návod přeložený do svého jazyka. Ražotājs Pepperl+Fuchs ar šo atbils bas apliecinājumu un CE zīmola lietojumu aps prina, ka produkts izgatavots sakaņā ar atbilstošajām Prohlášení o shodě s ES Eiropas vadlīnijām.
Seite 3
Pulscon LTC50, LTC51, LTC57 SI01136O-D EU-Konformitätserklärung/EU-Declaration of conformity/ Déclaration UE de conformité...
Pulscon LTC50, LTC51, LTC57 SI01136O-D Grundspezifikationen Gewählte Option Position Beschreibung Zulassung LTC5X-X-XXXXX-XXXXX- XXXXX ATEX II 1/2G Ex d [ia] IIC T6-T1 Ga/Gb ATEX II 1/2D Ex ta IIIC Txx°C Da/Db Elektrischer Ausgang LTC5X-X-XXXXX-XX X-XX XXXXX 4-Draht, 90 V AC ... 253 V AC, 4 mA ... 20 mA HART 4-Draht, 10,4 V DC ...
– Deckel bis zum Anschlag eindrehen. – Sicherungskralle am Deckel fest anziehen. Grundspezifikation, Option „Elektrischer Ausgang“ = AH • Schutzleiter am Gerät anschließen. Eigensicherheit • Das Gerät kann an die Pepperl+Fuchs-Service-Schnittstelle angeschlossen werden; Be- triebsanleitung berücksichtigen. Potentialausgleich • Gerät in den örtlichen Potentialausgleich einbeziehen.
Pulscon LTC50, LTC51, LTC57 SI01136O-D Allgemeine Hinweise Wenn nicht anders angegeben, beziehen sich die Positionen immer auf die Grundspezifikation. Hinweis! Zulässigen Temperaturbereich an der Sonde beachten. Auswahltabelle Zulassung Gehäuse ATEX II 1/2G Ex d [ia] IIC T6-T1 Ga/Gb GT20 Zweikammer, Alu beschichtet ATEX II 1/2D Ex ta IIIC Txx°C Da/Db...
Pulscon LTC50, LTC51, LTC57 SI01136O-D Diagramm/Diagram/ Beispieldiagramme zu den Temperaturtabellen/Example diagrams to the temperature tables/ Diagramme Diagrammes d'exemple aux tableaux des températures Abbildung/Figure/Figure 1 Version 1 Version 2 Umgebungstemperatur/Ambient temperature/Température ambiante Prozesstemperatur/Process temperature/Température de process...
Pulscon LTC50, LTC51, LTC57 SI01136O-D Sonden-Design: kompakt/Probe design: compact/Construction de sonde : compacte Sonde und Elektronikgehäuse/Probe and electronics housing/Sonde et boîtier de l'électronique : Zone 1 LTC50 Elektrischer Ausgang/Electrical output/Sortie électrique = AH, DH (TRC [09/08]) Gehäuse/Housing/Boîtier = A2 Temperaturklasse/ Temperature class/ Classe de température...
Pulscon LTC50, LTC51, LTC57 SI01136O-D Sonde/Probe/Sonde: Zone 20, Zone 21 Elektronikgehäuse/Electronics housing/Boîtier de l'électronique: Zone 21 LTC5X Elektrischer Ausgang/Electrical output/Sortie électrique = AH (TRC [09]) Gehäuse/Housing/Boîtier = A2, A3 – T = T + 9 K Elektrischer Ausgang/Electrical output/Sortie électrique= DH (TRC [08]) Gehäuse/Housing/Boîtier = A2, A3...
