Attach the Front Wheels
2
6
3
1 2 3
7
1
4
5
8
Front bottom View
10
4
5
7
8
9
6
1. Fit the front axle to the vehicle body.
2. Ensure that the bent end of the steering column passes through the hole
on the front axle linkage.
3. Insert eight Ø4x16 screws and tighten.
4. Slide the Ø12 washer onto the front axle.
5. Slide a bushing onto the front axle.
6. Slide a front wheel onto the front axle.
7. Slide a bushing onto the front axle.
8. Slide the Ø12 washer onto the front axle.
9. Tighten a lock nut to the end of the front axle with a spanner.
10. Fit the wheel cover to the front wheel. The stop point on the wheel must
match up with the stop slot on the wheel cover.
Repeat the procedure 4-10 to assemble the other front wheel.
