Attach the Rear Wheels
6
3
4
5
1. Slide a gear box onto the rear axle ("R" labeled gear box should be fit to the "R"
side of vehicle body; "L" labeled gear box should be fit to "L" side of vehicle body),
and keep the motor and the connector on the gear box pass through the larger hole
on the vehicle body.
2.Slide the rear wheel onto the rear axle. And keep the rear wheel match up with the
gear box.
3. Slide a bushing onto the rear axle, also keep it match up with the rear wheel.
4. Slide the Ø12 washer onto the rear axle.
5. Tighten a lock nut to the end of the rear axle with a spanner. Repeat for the other
rear wheel.
6.Fit the wheel covers to the rear wheels. The stop points on the wheels must match
up with the stop slots on the wheel covers.
8
9
Front bottom View
Rear bottom View
1
2
7. Fit the front bumper supports to the
front bumper linkage.
8. Fit the front bumper assembly to the
vehicle body.
9. Insert two Ø4x16 screws and tighten
with a screwdriver on each side.
7 7
7 7
