GB
Wear a breathing mask
Noise emission values
Idle mode
Sound pressure level LPA 93,5 dB(A) 88,1 dB(A)
Sound power level LWA 106,5 dB(A) 101,1 dB(A)
The quoted values are emission values and not
necessarily reliable workplace values. Although there
is a correlation between emission and immission
levels it is impossible to draw any certain conclusions
as to the need for additional precautions. Factors
with a potential influence on the actual immission
level at the workplace include the duration of impact,
the type of room, and other sources of noise etc.,
e.g. the number of machines and other neighboring
operations. Reliable workplace values may also vary
from country to country. With this information the
user should at least be able to make a better
assessment of the dangers and risks involved.
5. Technical data
AC motor 230V - 240V
Power P S1 1200 W S6 40% 1500 W
Idle speed n
0
Cutting-off wheel Ø 250 x Ø 30 x Ø 2.4 mm
Number of teeth
Table size 595 x 440 mm
Table width extension, left/right 595 x 250 mm
Table length extension, rear 440 x 320 mm
Cutting height max. 73 mm/90°
53 mm / 45°
Height adjustment infinite 0 -73 mm
Tilting saw blade infinite 0° - 45°
Extractor socket
6. Before putting the machine into
operation
Unpack the bench-type circular saw and check it
for damage which may have occurred in transit.
The machine has to be set up where it can stand
firmly, e.g. on a work bench, or it must be bolted
to a strong base.
All covers and safety devices have to be
properly fitted before the machine is switched
on.
20
04.06.2004 10:57 Uhr Seite 20
It must be possible for the saw blade to run
freely.
When working with wood that has been
processed before, watch out for foreign bodies
such as nails or screws etc.
Before you actuate the On/Off switch, make sure
that the saw blade is correctly fitted and that the
machine's moving parts run smoothly.
Before you connect the machine to the power
supply, make sure the data on the rating plate is
the same as that for your mains.
7. Assembly
Important! Pull out the power plug before
carrying out any maintenance, resetting or
assembly work on the cutting-off machine!
7.1 Assembling the base frame (Fig. 17/18)
Turn the saw upside down and place it on the
floor.
Use the hex screws and nuts to fasten the four
legs (40) loosely to the saw.
Now fasten the longitudinal struts and cross
struts (41) as well as the four center struts (42)
loosely to the legs.
Be sure to secure the hex screws and nuts only
loosely. Important: The longer struts have to be
50Hz
used on the sides.
Now mount the rubber feet (43) on the legs and
4300 min -1 turn the saw together with the base frame so
that it stands upright on the floor.
Finally, secure all the screws and nuts on the
24
base frame so that they are tight (Fig. 18).
7.2 Table width extension and length extension
(Fig. 19/20)
Use the screws and nuts to fasten the table
width extension and length extension (35/36)
loosely to the saw table (1) (Fig. 19).
Screw the supports (27) loosely onto the saw
housing and onto the table width extension or
length extension (short supports for the width
Ø 36 mm
extension, long supports for the length
extension).
Align the table width extension and length
extension level with the saw table (1).
Finally, tighten all screws. (Fig. 20)
7.3 Fitting / removing the saw blade guard (Fig. 3)
Mount the saw blade guard (2) on the splitter (5)
so that the screw fits through the hole (44) in the
splitter.
Do not tighten the screw (15) too far – the blade
guard must be able to move freely.
Fasten the extractor hose (13) to the extractor
