• RESET - channel: 27 (Stnd) - 27 (16b) - 30 (Extn)
• LAMP CONTROL - channel: 28 (Stnd) - 28 (16b) - 31 (Extn)
only with option LDmx On
ON
ON
ON
ON
OFF
OFF
IMPORTANT:
with SiFa option enabled, if the lamp is off or working in half power mode
some fans automatically decrease the rotating speed to reduce their noise to the half.
• PAN FINE - channel: 29 (16b) - 27 (Extn)
Operation with option Pan
Off
(Tilt conventionally represented at 15% and option Til
Operation with option Pan
On
(Tilt conventionally represented at 15% and option Til
ALPHA PROFILE 1200
BIT
%
EFFECT
255
100
COMPLETE RESET
Complete reset is activated passing
throug the unused range and staying
5 seconds in complete reset levels.
128
50.0
COMPLETE RESET
127
49.7
PAN / TILT RESET
Pan / Tilt reset is activated passing
throug the unused range and staying
5 seconds in Pan / Tilt reset levels.
77
30.0
PAN / TILT RESET
76
29.7
EFFECTS RESET
Effects reset is activated passing
throug the unused range and staying
5 seconds in Effects reset levels.
26
10.0
EFFECTS RESET
25
9.7
UNUSED RANGE
0
0.0
BIT
%
EFFECT
255
100
LAMP AT FULL POWER
Lamp ignition after 5 s
in full power levels.
Immediate transition
from half to full power.
180
70.5
LAMP AT FULL POWER
LAMP AT HALF POWER
179
70.0
Immediate transition
from full to half power.
Lamp ignition not allowed
in half power.
101
39.5
LAMP AT HALF POWER
100
39.0
LAMP OFF
Lamp switch off passing
throug the unused
range and staying 5 s in
Lamp OFF levels.
26
10.0
LAMP OFF
25
9.7
UNUSED RANGE
0
0.0
Off)
BIT
%
255
100
0
0.0
Off)
BIT
%
255
100
0
0.0
• TILT FINE - channel: 30 (16b) - 29 (Extn)
Operation with option Til
Off
(Pan conventionally represented at 0% and option Pan
Operation with option Til
On
(Pan conventionally represented at 0% and option Pan
• GOBO FINE - channel: 31 (16b) - 12 (Extn)
33
Off)
BIT
%
255
100
0
0.0
Off)
BIT
%
255
100
0
0.0
BIT
%
255
100
127
50.0
0
0.0
➔
Continua / Continue
