• BLADE UP 1 - channel: 12 (Stnd) - 12 (16b) - 13 (Extn)
• BLADE UP 2 - channel: 13 (Stnd) - 13 (16b) - 14 (Extn)
• BLADE DW 1 - channel: 14 (Stnd) - 14 (16b) - 15 (Extn)
• BLADE DW 2 - channel: 15 (Stnd) - 15 (16b) - 16 (Extn)
• BLADE RG 1 - channel: 16 (Stnd) - 16 (16b) - 17 (Extn)
ALPHA PROFILE 1200
BIT
%
EFFECT
255
100
BLADE IN
127
50.0
0
0.0
BLADE OUT
BIT
%
EFFECT
255
100
BLADE IN
127
50.0
0
0.0
BLADE OUT
BIT
%
EFFECT
255
100
BLADE IN
127
50.0
0
0.0
BLADE OUT
BIT
%
EFFECT
255
100
BLADE IN
127
50.0
0
0.0
BLADE OUT
BIT
%
EFFECT
255
100
BLADE IN
127
50.0
BLADE OUT
0
0.0
• BLADE RG 2 - channel: 17 (Stnd) - 17 (16b) - 18 (Extn)
• BLADE LF 1 - channel: 18 (Stnd) - 18 (16b) - 19 (Extn)
• BLADE LF 2 - channel: 19 (Stnd) - 19 (16b) - 20 (Extn)
Important:
The sum of the levels of channel couples 12-13, 14-15, 16-17 and 18-19, with respect
to the metal bands on the beam shaper, cannot be over 152% (76% for each of the
two channels). If you attempt to go over this threshold, the projector software will
automatically limit the two channel levels, balancing them proportionally. For example:
1. If you set channel 12 and channel 13 from the control desk, both at 100%
(100+100=200%: unfeasible), the software will therefore force both channels
down to 76% (76+76=152%: feasible).
2. If you set channel 12 at 100% and channel 13 at 80% (100+80=180%:
unfeasible), the software will therefore force channel 12 down to 86% and
channel 13 down to 66% (86+66=152%: feasible)
Important:
The lamp automatically dim to half power in any condition in which the blades
completely shut the light beam.
• FRAMING ROTATION - channel: 20 (Stnd) - 20 (16b) - 21 (Extn)
31
BIT
%
EFFECT
255
100
BLADE IN
127
50.0
0
0.0
BLADE OUT
BIT
%
EFFECT
255
100
BLADE IN
127
50.0
0
0.0
BLADE OUT
BIT
%
EFFECT
255
100
BLADE IN
127
50.0
0
0.0
BLADE OUT
BIT
%
255
100
127
50.0
0
0.0
Continua / Continue
➔
