PROBLEM
Only black and white images are displayed.
The camera is not transmitting.
It is not possible to hear the baby on the
parental unit.
Interference or poor reception.
If the baby unit has lost connection with the
parental unit.

8. TECHNICAL SPECIFICATIONS

Frequency
Operating Range
Nº of configurable channels
Power (parent unit) Input:
Power (parent unit) Output:
Rechargeable battery for sasasmonitor
Power (baby unit) Input:
Power (baby unit) Output:
Operating time with battery fully charged (parent unit)
LCD Screen size
9. PRODUCT DISPOSAL INFORMATION
· Remember to dispose of the product responsibly.
· Do not mix products bearing the crossed -out bin symbol with your
general household waste.
· For the correct collection and treatment of these products take them
to the collection points designated by your local authority. Alternatively
contact the retailer who sold you the product.
POSSIBLE CAUSE
Check whether the camera is in night
vision/infrared mode.
The camera has not been turned on.
Camera: power adapter not plugged in.
VOX mode or standby mode is activated.
The volume setting of the parental unit is
too low.
Other electronic devices may be interfering
with the signal.
The camera and monitor may be too far apart.
The battery charge level may be too low.
The camera or monitor may be too close to
many metal objects.
The camera and monitor may be too far apart.
Connection between the two units is
momentarily lost.
The connection between the two units
is lost.
2.4GHz FHSS
240m (straight line and open space)
2
100-240 V CA - 50/60 Hz
5 V – 1A
3.7V 1200 mAh
100-240 V CA - 50/60 Hz
5 V – 1A
Approximately 8 hours
3.5"
15
SOLUTION
In order to view the images in colour, increase
the level of light in the room the camera is in or
check there is nothing covering the camera´s
light sensor (II).
Press the on / off button on the camera (I)
and keep pressing for 2 seconds.
Plug in the power adapter.
To view the monitored area continuously,
switch off the VOX mode or power saving
mode on the monitor.
Set the volume at the highest level. Check
section 5.2.2.
Move them away from the device.
Extend the antenna (15) of the monitor, and
in case it is still out of range move the monitor
closer to the camera.
Plug in the power adapter.
Move them away from the device.
Extend the monitor antenna, and in case it is
still out of range move the monitor closer to
the camera.
Restore the units by disconnecting them from
the power supply.
Wait about 15 seconds before reconnecting
them.
Allow one minute for the baby unit and the
parent unit to synchronize.
Pair the camera and monitor again.See
section 5.2.10.1.1.
Hereby, Miniland S. A. declares that this "89505
digimonitor 3.5" easy is in compliance with
the essential requirements and other relevant
provisions of Directive 2014/53/UE.
ENGLISH
