ENGLISH
4. Press the OK / zoom button (10).
Now you can select one of the three options described below:
1. Change of temperature measurement unit:
a. The default temperature measurement unit is ºC, if you want to change
from ºC to ºF, press the OK / zoom button (10) when it is over this option.
b. Press the right (7) or left (9) navigation button until the desired
temperature measurement unit is selected.
2. Select the temperature at which you want to set the sound alert:
a. Press the down navigation button (8) until it is over this option.
b. Press the OK / zoom button (10).
c. Using the side navigation buttons, you can select from a higher or
lower temperature range.
d. Once you have selected the range you want to change, press the up
(6) or down (8) navigation button to set the temperature limit. You can
set the lower temperature limit between 0ºC and 25ºC (32ºF and 75ºF)
and the higher limit between 25º and 35ºC (76ºF and 95ºF).
3. To activate and cancel the temperature sound alert:
a. Press the up (6) or down (8) navigation button until the temperature
alert activation icon is highlighted.
b. Press the OK / zoom button (10) to activate or cancel the alarm.
Note 1: If the alarm is activated the alert will sound when the
temperature is out of the desired range.
When the alert is sounding, press any button to turn it off.
If there is no response, the alert will sound for one minute, provided
the temperature remains over or under the limits set, and then stop;
it will sound again after three minutes.
Note 2: If the sound alert is turned off, you will be able to see the
temperature flashing in red on the top right-hand part of the LCD
screen (G) while it is over or under the set limits.
5.2.10.4. SETTING MENU
5.2.10.4.1. FACTORY SETTINGS
If you want, you can reset your monitor to go back to the factory settings.
To do this:
1. Press the menu button (5) to display the menu.
2. Press the right (7) or left (9) navigation button until the settings wheel
icon is highlighted.
3. Press the down (8) navigation button until the reset icon is highlighted.
4. Press the OK / zoom button (10) three times to select and confirm this
option and reset the monitor to the factory settings.
Note: In case the monitor is completely blocked, you can press the
reset button (16) on the back of the monitor.
7. TROUBLESHOOTING
PROBLEM
No reception on the monitor.
Unable to charge the battery to the parent unit.
5.2.10.4.2. SOUND ALERTS ON / OFF MENU
5.2.10.4.2.1. OUT OF RANGE SOUND ALERT
By default, when the monitor is further than the allowed distance away
from the camera (check the technical specifications) a sound alert is
activated consisting of two double beeps every 3 seconds. If you do not
want the monitor to warn you with a sound alert, you can turn this feature
on or off as described below:
1. Press the menu button (5) on the monitor to access the main menu.
2. Press the left (9) or right (7) navigation button until the wheel settings
icon is highlighted.
3. Press the down (8) navigation button until the alerts icon is highlighted.
4. Press the OK / zoom button (10) and then press the OK / zoom button
(10) again to activate or cancel the out of range sound alert.
Note: If the sound alert is turned on and your monitor is emitting a
sound warning, bring the monitor close to the camera or press any
button to turn it off.
5.2.10.4.2.2. LOW MONITOR BATTERY SOUND ALERT
By default, when the monitor battery level is low a sound alert is activated
and the low monitor battery icon (H) and the 4 LED indicators (3) will
flash. About 10 minutes may elapse from the time when the alert sounds
until the monitor is turned off completely, if not charging.
The sound alert lasts for one minute, but you can turn it off by pressing
any button on the front panel of the baby monitor.
If you do not want the monitor to warn you with a sound alert, you can
turn this feature on or off as described below:
1. Press the menu button (5) on the monitor to access the main menu.
2. Press the left (9) or right (7) navigation button until the wheel settings
icon is highlighted.
3. Press the down (8) navigation button until the alerts icon is highlighted.
4. Press the OK/zoom button (10) to display the sub-menu.
5. Press the down (8) navigation button until the low monitor battery
sound alert icon is highlighted.
6. Press the OK/ zoom button (10) to activate or cancel the low monitor
battery sound alert.
If the audible alarm is deactivated, the charging symbol (H) at the top
of the display and the 4 green LEDs (3) will flash for one minute or until
you touch a button on the monitor.
6. MAINTENANCE
• Clean the surfaces of the camera and monitor with a soft, lint-free cloth.
• If the units become dirty, use a lightly dampened cloth to wipe surfaces,
taking care to not allow water into any openings.
• Never use cleaning agents or solvents.
POSSIBLE CAUSE
Camera not turned on.
Monitor not turned on.
Camera: not plugged in to the power adapter.
Monitor: The power adapter is not plugged.
Monitor out of range.
Connection lost between the monitor and a
camera already linked.
A wrong camera has been selected.
AC/DC adapter is not plugged in.
14
SOLUTION
Press the on / off button (I) and keep pressing
for at least 2 seconds.
Press the on / off button (1) and keep pressing
for 4 seconds.
Plug in the power adapter.
Plug in the power adapter.
Extend the monitor antenna (15) and if it is still
out of range, bring the monitor closer to the
camera.
Extend the antenna (15) of the monitor, and
in case it is still out of range move the monitor
closer to the camera. Check section: 5.2.10.1.1.
Change the camera number you are watching.
See 5.2.10.1.3.
Plug in the power adapter.
