4. "Many-to-one" scenario:
- The RX receiver device must be set to the same signal channel as
the paired source in order to output the signal.
*Troubleshooting guide:
If no signal is seen on the monitor (connected to the CSW320
receiver), please make sure that both devices (CSW320 transmitter
and receiver) are
(1) are switched to the "switch mode"
(2) have been coupled with each other or repeat the process again
(3) are set to the same channel ID.
** Instructions for pairing the devices (pairing mode)
(1) Set the toggle switches of TX and RX to SP mode and connect
the devices to the power supply.
(2) Connect the TX and RX via HDMI cable in the HDMI-IN jack. The
After that, the devices are connected to each other and the HDMI
cable can be removed again.
18
