1 Important Information

Exclusion of liability

The delivery of replacement parts, maintenance and upkeep may only be carried out by authorized personnel. We
assume no liability whatsoever for coincidental, special or consequential damage resulting from upkeep or
maintenance carried out by third parties or for the use of equipment or individual parts manufactured by third parties,
including loss of profits, commercial losses of any kind, financial losses or losses due to the injury of persons.
Pos: 15 /926-SycoTec/1_Wichtige Hinweise_Statmatic Plus/10_Geraeteuebersicht (Statmatic Plus) @ 8\mod_1345989675044_6.doc @ 68463 @ 2 @ 1

Overview of Device

Top cover
Control membrane keyboard
Plug-in position for turbine adapter
(1x Type 32 / 2x Type 33)
Care coupling
INTRAmatic ISO 3964
(2x Type 32 / 1x Type 33)
Collection pan
Collet care nozzle
Absorption fleece (2x)
Front cover
Filling opening for dental oil
Filling opening for cleaner
Power switch
Power fuse tray
Input for power supply
Rating plate
Compressed air input
Compressed air
regulator
Compressed air display
Pos: 16 /926-SycoTec/1_Wichtige Hinweise_Statmatic Plus/11_Bedienfolientastatur (Statmatic Plus) @ 8\mod_1345990929001_6.doc @ 68482 @ 2 @ 1
Page 27
1
2
3
4
5
9
11
12
13
14
6
7
8
10
15
16
STATMATIC PLUS 32 / 33
17
EN
