Connection

PoE Camera Power + Data Out
PoE Camera
Attention:There are two connection modes:
1. For non-PoE router,pls connect the camera by a PoE switch or a PoE injector.
2. For a POE NVR,pls connect the camera directly to the POE NVR, then follow the
below steps.
6
Internet
DC 48V
LAN IN
PoE Injector
or
PoE Switch
PoE NVR
iPhone / iPad
Android Phone
Router
Router
Phone PC
