I. Move the shaving heads quickly over your skin, making both straight and circular movements. Shaving on a dry face gives the best results. Your skin may need 2 or 3 weeks to get accustomed to the Philips system.
◗ For easy and optimal cleaning, the Philips Action Clean (shaving head cleaner, type HQ100) is available.Ask your Philips dealer for information. The Philips Action Clean may not be available in all countries. Contact the Customer Care Centre in your country about the availability of this accessory.
All manuals and user guides at all-guides.com ENGLISH Every week: shaving unit and hair chamber Switch the shaver off, remove the mains plug from the wall socket and pull the appliance plug out of the shaver. Clean the top of the appliance first, using the brush supplied.
Seite 5
All manuals and user guides at all-guides.com ENGLISH Turn the wheel anticlockwise (1) and remove the retaining frame (2). Remove and clean the shaving heads (cutters and guards) one by one. Do not mix up the cutters and the guards. This is essential since each cutter has been ground with its corresponding guard for optimal performance.
Seite 6
All manuals and user guides at all-guides.com ENGLISH heads, follow steps 1 to 4 described above. After cleaning, lubricate the central point on the inside of the guards with a drop of sewing machine oil to prevent wear of the shaving heads. Trimmer Clean the trimmer every time you have used it.
Seite 7
All manuals and user guides at all-guides.com ENGLISH Replace damaged or worn shaving heads with HQ4« Philips shaving heads only. Switch the shaver off, remove the mains plug from the wall socket and pull the appliance plug out of the shaver.
Care Centre in your country (you will find its phone number in the worldwide guarantee leaflet). If there is no Customer Care Centre in your country, turn to your local Philips dealer or contact the Service Department of Philips Domestic Appliances and Personal Care BV.
Seite 9
All manuals and user guides at all-guides.com ENGLISH Cause 2: long hairs are obstructing the shaving heads. ◗ Clean the cutters and guards with the brush supplied. See chapter 'Cleaning and maintenance', section 'Every two months: shaving heads'. Cause 3: the shaving heads are damaged or worn. ◗...
All manuals and user guides at all-guides.com DEUTSCH Wichtig Lesen Sie diese Bedienungsanleitung vor dem ersten Gebrauch des Geräts gründlich durch und bewahren Sie sie zur späteren Einsichtnahme auf. ◗ Verwenden Sie ausschließlich das mitgelieferte Netzkabel. ◗ Verwenden Sie auf keinen Fall ein beschädigtes Netzkabel.
Motor aktivieren. Reinigung und Wartung Regelmäßige Reinigung sorgt für bessere Rasur und verlängert die Nutzungsdauer des Geräts. ◗ Mit dem Philips "Action Clean" HQ100 können Sie alle Scherköpfe schnell und gründlich reinigen. Fragen Sie Ihren Philips- Händler. Möglicherweise ist der Philips Action Clean...
All manuals and user guides at all-guides.com DEUTSCH Scherkopfreiniger nicht in jedem Land erhältlich. Das Philips Service Center in Ihrem Land kann Ihnen Auskunft über die Verfügbarkeit dieses Zubehörs geben. Sie können den Rasierer auch auf folgende Weise reinigen: Einmal wöchentlich: Schereinheit und Bartfangkammer Schalten Sie das Gerät aus, ziehen Sie das...
Seite 13
All manuals and user guides at all-guides.com DEUTSCH Alle zwei Monate: Scherköpfe Schalten Sie das Gerät aus, ziehen Sie das Netzteil aus der Steckdose und den Gerätestecker vom Rasierer. Drücken Sie den Entriegelungsknopf (1) und nehmen Sie die Schereinheit ab (2). Drehen Sie das Rädchen gegen den Uhrzeigersinn (1) und nehmen Sie den Scherkopfhalter heraus (2).
Seite 14
All manuals and user guides at all-guides.com DEUTSCH Setzen Sie Scherköpfe und Scherkopfhalter wieder in die Schereinheit ein (1) und drehen Sie das Rädchen im Uhrzeigersinn fest (2). Setzen Sie die Schereinheit wieder auf den Rasierer. Für eine besonders gründliche Reinigung können Sie die Scherköpfe alle sechs Monate in eine fettlösende Flüssigkeit (z.
Tauschen Sie die Scherköpfe alle zwei Jahre aus, um weiterhin optimale Rasierergebnisse zu erzielen. Ersetzen Sie beschädigte oder abgenutzte Scherköpfe ausschließlich durch Philips HQ4« Scherköpfe. Schalten Sie das Gerät aus, ziehen Sie das Netzteil aus der Steckdose und den Gerätestecker vom Rasierer.
(Scherkopf-Reinigungsflüssigkeit) - HQ110 Philips Shaving Head Cleaner (Reinigungsspray für Scherköpfe) Garantie und Kundendienst Benötigen Sie weitere Informationen oder treten Probleme auf, wenden Sie sich bitte an Ihren Philips-Händler oder setzen Sie sich mit einem Philips Service-Center in Ihrem Land in...
Seite 17
All manuals and user guides at all-guides.com DEUTSCH Verbindung (Tel. Nr. 0180/5356767). Besuchen Sie auch die Philips Website www.philips.com. Problembehebung Schlechte Rasur Ursache 1: Die Scherköpfe sind verschmutzt. Der Rasierer wurde nicht gründlich genug oder seit längerer Zeit nicht mehr gereinigt.
All manuals and user guides at all-guides.com FRANÇAIS Important Avant d'utiliser l'appareil, lisez les instructions ci- dessous et conservez ce mode d'emploi pour un usage ultérieur. ◗ Utilisez exclusivement le cordon d'alimentation fourni. ◗ N'utilisez pas un cordon d'alimentation endommagé. ◗...
Nettoyage et entretien Nettoyez régulièrement l'appareil pour obtenir de meilleurs résultats de rasage. ◗ Pour un nettoyage facile et rapide des têtes, vous pouvez utiliser l'Action Clean de Philips (type HQ100), disponible auprès de votre revendeur ou Centre Service Agréé Philips.
All manuals and user guides at all-guides.com FRANÇAIS Il est possible que l'Action Clean de Philips ne soit pas disponible dans tous les pays. Pour plus d'informations, contactez le Service Consommateurs Philips de votre pays. Vous pouvez également nettoyer le rasoir de la manière suivante :...
Seite 21
All manuals and user guides at all-guides.com FRANÇAIS Tous les deux mois: têtes de rasage Arrêtez l'appareil, débranchez la fiche de la prise de courant, puis retirez la fiche de l'appareil. Appuyez sur le bouton de déverrouillage (1) et enlevez l'unité de rasage (2). Faites tourner la molette dans le sens inverse des aiguilles d'une montre (1) et enlevez la plaque de fermeture (2).
Seite 22
All manuals and user guides at all-guides.com FRANÇAIS Remontez les têtes de rasage sur l'unité de rasage, fixez la plaque de fermeture sur l'unité (1) et tournez la molette dans le sens des aiguilles d'une montre (2). Remontez l'unité de rasage sur le rasoir. Pour un nettoyage à...
Seite 23
Remplacez les têtes de rasage endommagées ou usagées exclusivement par des têtes de rasage HQ4« Philips. Arrêtez l'appareil, débranchez la fiche de la prise de courant, puis retirez la petite fiche de l'appareil.
- Philips Action Clean HQ100 (nettoyeur de têtes de rasage) - Philips Action Clean Recharge HQ101 (produit liquide de nettoyage pour HQ100). - Philips Spray HQ110 (spray de nettoyage de tête de rasage). Garantie et service Pour toute réparation/information, ou en cas de problème, visitez notre website: www.philips.com.
Seite 25
All manuals and user guides at all-guides.com FRANÇAIS contactez votre distributeur ou le Service Department de Philips Domestic Appliances and Personal Care BV. Dépannage Les résultats de rasage se dégradent Cause 1: Les têtes de rasage sont sales. L'appareil n'a pas été nettoyé à fond ou il n'a pas été...
Seite 26
All manuals and user guides at all-guides.com NEDERLANDS Belangrijk Lees deze gebruiksaanwijzing zorgvuldig door voordat u het apparaat gaat gebruiken. Bewaar de gebruiksaanwijzing om hem indien nodig te kunnen raadplegen. ◗ Gebruik uitsluitend het bijgeleverde snoer. ◗ Gebruik het netsnoer niet indien het beschadigd is.
Scheren op een droog gezicht geeft het beste resultaat. Uw huid kan 2 tot 3 weken nodig hebben om aan dit Philips-scheersysteem te wennen. Schakel het scheerapparaat uit door de aan/uitknop naar stand 0 te duwen. Plaats na gebruik altijd de beschermkap op het apparaat om beschadiging te voorkomen.
Seite 28
All manuals and user guides at all-guides.com NEDERLANDS De Philips Action Clean is mogelijk niet in alle landen verkrijgbaar. Neem contact op met het Customer Care Centre in uw land over de verkrijgbaarheid van dit accessoire. U kunt het apparaat ook op de volgende wijze...
Seite 29
All manuals and user guides at all-guides.com NEDERLANDS Elke twee maanden: scheerhoofden Schakel het scheerapparaat uit, haal de stekker uit het stopcontact en trek het stekkertje uit het apparaat. Druk op de ontgrendelknop (1) en verwijder de scheerunit (2). Draai het wieltje linksom (1) en verwijder de opsluitplaat (2).
Seite 30
All manuals and user guides at all-guides.com NEDERLANDS Plaats de scheerhoofden terug in de scheerunit. Plaats de opsluitplaat terug in de scheerunit (1) en draai het wieltje rechtsom (2). Plaats de scheerunit terug op het apparaat. Voor extra grondige reiniging kunt u de scheerhoofden elke zes maanden schoonmaken met een ontvettende vloeistof (bijv.
Seite 31
Vervanging Vervang de scheerhoofden om de twee jaar, voor een optimaal scheerresultaat. Vervang beschadigde of versleten scheerhoofden uitsluitend door HQ4« Philips scheerhoofden. Schakel het scheerapparaat uit, haal de stekker uit het stopcontact en trek het apparaatstekkertje uit het apparaat. Druk op de ontgrendelknop (1) en verwijder de scheerunit (2).
Garantie & service Als u informatie nodig heeft of als u een probleem heeft, bezoek dan onze website (www.philips.com), of neem contact op met het Philips Customer Care Centre in uw land (u vindt het telefoonnummer in het 'worldwide guarantee' vouwblad).
All manuals and user guides at all-guides.com NEDERLANDS Als er geen Customer Care Centre in uw land is, ga dan naar uw Philips dealer of neem contact op met de afdeling Service van Philips Domestic Appliances and Personal Care BV.
Seite 34
All manuals and user guides at all-guides.com NEDERLANDS Oorzaak: het scheerapparaat is niet aangesloten op netspanning. ◗ Steek de stekker in het stopcontact.
All manuals and user guides at all-guides.com ESPAÑOL Importante Antes de usar el aparato, lea atentamente estas instrucciones y consérvelas por si necesitara consultarlas en el futuro. ◗ Use únicamente el cable que se suministra. ◗ No utilice un cable dañado. ◗...
HQ100). Para más información, consulte con su vendedor o distribuidor Philips. Es posible que Philips Action Clean no esté disponible en todos los países. Consulte al Servicio de atención al cliente de su país acerca de la...
All manuals and user guides at all-guides.com ESPAÑOL También puede limpiar la afeitadora de la siguiente manera: Todas las semanas: unidad afeitadora y cámara de recogida de pelo Desconecte la afeitadora, desenchufe la clavija adaptadora de la red y saque la clavija de la afeitadora.
Seite 38
All manuals and user guides at all-guides.com ESPAÑOL Cada dos meses: conjuntos cortantes Desconecte la afeitadora, desenchufe la clavija adaptadora de la red y saque la clavija de la afeitadora. Presione el botón de liberación (1) y saque la unidad afeitadora (2). Gire la ruedecilla en sentido contrario al de las agujas del reloj (1) y saque el marco de retención (2).
Seite 39
All manuals and user guides at all-guides.com ESPAÑOL Cepille el protector. Vuelva a colocar los conjuntos cortantes en la unidad afeitadora.Vuelva a poner el marco de retención en la unidad afeitadora (1) y gire la ruedecita en el sentido de las agujas del reloj (2).
Para lograr un resultado óptimo en el afeitado, sustituya los conjuntos cortantes cada dos años. Sustituya los conjuntos cortantes gastados o dañados sólo por conjuntos cortantes Philips HQ4«. Apague la afeitadora, saque la clavija del enchufe de red y saque la clavija del...
All manuals and user guides at all-guides.com ESPAÑOL Presione el botón de liberación (1) y saque la unidad afeitadora (2). Gire la ruedecita en sentido contrario al de las agujas del reloj (1) y quite el marco de retención (2). Saque los conjuntos cortantes y coloque unos nuevos en la unidad afeitadora.
Philips en www.philips.com, o póngase en contacto con el Servicio Philips de Atención al Cliente de su país (hallará el número de teléfono en el folleto de la Garantía Mundial). Si en su país no hay Servicio Philips de Atención al Cliente, diríjase a su...
Seite 43
All manuals and user guides at all-guides.com ESPAÑOL Causa 2: hay pelos largos obstruyendo los conjuntos cortantes. ◗ Limpie las cuchillas y los protectores con el cepillo que se suministra. Consulte el capítulo 'Limpieza y mantenimiento', apartado "Cada dos meses: conjuntos cortantes". Causa 3: los conjuntos cortantes están gastados o dañados.
Seite 44
All manuals and user guides at all-guides.com ITALIANO Importante Prima di usare l'apparecchio leggete con attenzione queste istruzioni e conservatele per eventuali riferimenti futuri. ◗ Utilizzate esclusivamente il cavo in dotazione. ◗ Non usate il cavo nel caso risulti danneggiato. ◗...
Una pulizia regolare garantisce i migliori risultati di rasatura. ◗ Per una pulizia facile e ottimale utilizzare Philips Action Clean (tipo HQ100, per la pulizia delle testine dei rasoi). Chiedi informazioni al rivenditore. Il Philips Action Clean potrebbe non essere disponibile in tutti i paesi.
Seite 46
All manuals and user guides at all-guides.com ITALIANO Per la pulizia del rasoio, è possibile inoltre procedere come segue: Ogni settimana: l'unità di rasatura e la vaschetta di raccolta peli. Spegnete il rasoio, togliete la spina dalla presa di corrente e lo spinotto dal rasoio. Pulire la parte superiore dell'apparecchio servendovi dello spazzolino in dotazione.
Seite 47
All manuals and user guides at all-guides.com ITALIANO Premete il pulsante di sgancio (1) e togliete l'unità di rasatura. Girate la rotella in senso antiorario (1) e togliete il telaietto di fissaggio (2). Togliete e pulite testine (lama e paralama) una ad una.
Seite 48
All manuals and user guides at all-guides.com ITALIANO Rimettete le testine nell'unità di rasatura. Rimettete il telaietto di fissaggio nell'unità di rasatura (1) e ruotate la rotella in senso orario (2). Rimettete l'unità di rasatura sul rasoio. Per una pulizia ancora più accurata, immergete le testine di rasatura in un liquido sgrassante (ad esempio alcool) ogni sei mesi.
Seite 49
Per sostituire le testine di rasatura danneggiate o usurate, utilizzate esclusivamente le testine originali Philips HQ4«. Spegnete il rasoio, togliete la spina dalla presa di corrente e lo spinotto dal rasoio. Premete il pulsante di sgancio (1) e togliete l'unità...
Accessori Sono disponibili i seguenti accessori: - Testine di rasatura Philips HQ4« - HQ100 Philips Action Clean (per pulire le testine di rasatura). - HQ101 Philips Action Clean ricarica (liquido per la pulizia delle testine di rasatura). - HQ110 Philips Head Cleaner (spray per la pulizia delle testine).
All manuals and user guides at all-guides.com ITALIANO sia un Centro Assistenza Clienti, contattate il vostro rivenditore di fiducia oppure il Service Department of Philips Domestic Appliances and Personal Care BV (l'indirizzo e il numero di fax sono riportati qui sotto). Ricerca e risoluzione guasti Prestazioni di rasatura ridotte Causa 1: le testine di rasatura sono sporche.
Seite 52
All manuals and user guides at all-guides.com ITALIANO Causa: il rasoio non è collegato alla presa di corrente. ◗ Inserite la spina nella presa di corrente.
Seite 53
All manuals and user guides at all-guides.com PORTUGUÊS Importante Antes da primeira utilização, leia estas instruções com atenção e guarde-as para uma eventual consulta futura. ◗ Utilize apenas o cabo de alimentação fornecido. ◗ Se o fio estiver estragado, não use a máquina. ◗...
Philips Action Clean (líquido de limpeza das cabeças, tipo HQ100). Informe-se num distribuidor Philips. O Philips Action Clean poderá não se encontrar disponível em todos os países. Contacte o Centro de Informação ao Consumidor do seu país para...
All manuals and user guides at all-guides.com PORTUGUÊS se informar sobre a disponibilidade deste acessório. Também poderá limpar a máquina da seguinte forma: Semanalmente: unidade de corte e câmara de recolha dos pêlos Desligue a máquina, retire a ficha da tomada eléctrica e puxe a ficha de ligação para fora da máquina.
Seite 56
All manuals and user guides at all-guides.com PORTUGUÊS Aparador Desligue a máquina, retire a ficha da tomada eléctrica e puxe a ficha de ligação para fora da máquina. Pressione o botão de desengate (1) e retire a unidade de corte (2). Rode o anel para a esquerda (1) e retire a armação de retenção (2).
Seite 57
All manuals and user guides at all-guides.com PORTUGUÊS Volte a introduzir as cabeças na unidade de corte. Reponha a armação de retenção na unidade de corte (1) e rode o anel para a direita (2). Volte a colocar a unidade de corte na máquina.
Seite 58
Substitua as cabeças estragadas ou gastas apenas por cabeças de origem HQ4« Philips. Desligue a máquina, retire a ficha da tomada eléctrica e puxe a ficha de ligação para fora da máquina.
- HQ110 Philips Head Cleaner (spray para limpeza das cabeças). Garantia e assistência Se necessitar de informações ou se tiver qualquer problema, por favor visite o site da Philips: www.philips.pt ou contacte o Centro de Informação ao Consumidor Philips do seu país (o...
Se não existir um Centro de Informação ao Consumidor Philips no seu país, dirija-se ao agente Philips local ou contacte o Departamento de Service da Philips Domestic Appliances and Personal Care BV.
Seite 61
All manuals and user guides at all-guides.com PORTUGUÊS Causa: a máquina não está ligada à corrente. ◗ Ligue a ficha à tomada eléctrica.
All manuals and user guides at all-guides.com TÜRKÇE Önemli Lütfen cihazı kullanmadan önce verilen talimatları okuyun. İleride başvurmak için bu talimatları saklayın. ◗ Cihazı, yalnızca cihazla birlikte satılan elektrik kordonunu ile kullanın. ◗ Hasarlı elektrik kordonunu kullanmayın. ◗ Cihazın elektrik kordonu hasar görmüşse, kesinlikle orijinal modeli ile değiştirilmelidir.
Temizlik & bakım Cihazı düzenli olarak temizlemek daha iyi tıraş performansını sağlar. ◗ Etkili ve kolay temizlik Philips Action Clean kullanınız. (Tıraş başlığı temizleyicisi HQ100) Daha detaylı bilgi için yetkili Philips bayilerine başvurun. Philips Action Clean (Tıraş başlığı temizleyicisi) tüm ülkerlerde bulunmayabilir.
All manuals and user guides at all-guides.com TÜRKÇE Her hafta: tıraş ünitesi ve kıl toplama haznesi Tıraş makinasını kapatarak, şarj cihazının fişini prizden ve tıraş makinasından çekin. Cihazın üstünü kutudan çıkan fırçayla temizleyin. Ayırma düğmesine(1) basınız ve tıraş ünitesini (2) çıkartın. Tıraş...
Seite 65
All manuals and user guides at all-guides.com TÜRKÇE Çarkı, saatin aksi yönünde(1) döndürünüz ve tespit çerçevesini (2) çıkartın. Tıraş başlıklarını (bıçak ve koruyucu parçayı) tek tek çıkartınız ve temizleyin. Bıçak ve koruyucu parçaları karıştırmayınız. Bu çok önemlidir! Çünkü her bıçak, kendi koruyucu parçası...
Seite 66
All manuals and user guides at all-guides.com TÜRKÇE başlıklarını yerinden çıkarmak için yukarıdaki 1ile 4 maddelerini takip edin.Tıraş başlıklarını temziledikten sonra koruyucuların merkez noktasını yağlamak için bir damla makina yağı damlatın. Bu sayede tıraş başlıklarının aşınması önlenecektir. Düzeltici Her kullanımdan sonra düzelticiyi temizleyiniz. Tıraş...
Seite 67
All manuals and user guides at all-guides.com TÜRKÇE Hasarlı veya yıpranmış tıraş başlıkları sadece Philips HQ4« tıraş başlıkları ile değiştirilmelidir. Tıraş makinesini kapatın, fişini prizden çekin, cihazın fişini cihazdanda çıkarın. Ayırma düğmesine(1) basınız ve tıraş ünitesini (2) çıkartın. Çarkı saat yönünün tersine (1) döndürerek, tutucu çerçeveyi (2) çıkartın.
Seite 69
All manuals and user guides at all-guides.com TÜRKÇE Sebep 2: Uzun kıllar tıraş başlıklarının çalışmasını önlüyor. ◗ Bıçakları ve koruyucu parçaları fırça ile temizleyin. Bkz. "Temizlik ve bakım" bölümü her iki ayda bir: tıraş başlıkları. Sebep 3: tıraş başlıkları zarar görmüş veya aşınmıştır.
