Drilling with the power tool at low rotational speeds may result in overheating of the motor. Make
regular breaks in your work or allow the device to work at maximum rotational speed without load
for about 3 minutes.
HOOK
The drill/driver has a practical hook (6) that can be used for example to hang the power tool on a fitter's
belt during work at heights.
MAINTENANCE AND STORAGE
The power tool should be cleaned after each use.
Do not use water or other liquids to clean the power tool.
The driver/drill should be cleaned with a piece of dry cloth or with a jet of compressed air at low
pressure.
Do not use any cleaning agents or solvents as they may damage the plastic parts.
Clean the ventilation slots in the motor housing regularly so as to prevent overheating of the power
tool.
In the event of excessive sparking of the commutator, have the condition of the carbon brushes of the
motor checked by a qualified person.
Always store the drill/driver in a dry place inaccessible to children.
REPLACEMENT OF THE CHUCK
The chuck is screwed onto the thread of the spindle and also secured with a screw.
Set the rotation direction switch (5) in the central position.
Open the jaws of the chuck (1) and unscrew the fixing screw (left-hand thread) (fig. H).
Put an Allen key in the chuck and gently tap the other end of the key.
Unscrew the chuck.
In order to install the chuck, perform the above actions in a reverse order.
Any and all defects must be removed by service companies authorized by the manufacturer.
RATING DATA
Parameter
Battery voltage
Battery type
Battery capacity
Range of rotational speed in the idle gear
Range of chuck
Range of torque control
Maximum torque
Protection class
Weight
Year of manufacture

SERVICE AND MAINTENANCE

TECHNICAL PARAMETERS

Cordless drill/driver
19
Value
14,4 V DC
Li-Ion
2000 mAh
0-400/0-1100 min -1
1-13 mm
1-20 plus drilling
34 Nm
III
1,52 kg
2015
