6. INTRODUCTION TO PANEL

SETTING ENTRY:

Press the
If F1.14 = 0, you can set all the parameters within F1~F5.
If F1.14 = 1, you can only set all parameters within F2~F5.
If F1.14 = 1 and you need to set the parameters within F1 menu, you can press the calibration switch button until the F1 menu is
entered.

F1 PARAMETER SETTING OF SCALE

F1.1 Measuring Range
Selectable parameters: 3~200000 (default value: 6)
F1.2 Decimal Places
Selectable parameters: 0 ---- no decimal point
F1.3 Number of Divisions
Selectable parameters: 1 (default value), 2, 5, 10, 20, 50
F1.4 Calibration Unit
Selectable parameters: 0 ---- kg (default value)
F1.5 Gravitational Acceleration
Selectable parameters: 9.70000~9.99999. Default value = 9.79455.
F1.6 Null-point Calibration
[E-SCL] Keeping empty the scale
Remove the weights on the weighing platform to guarantee the scale is in the empty state. Press the
play [0 cal]. The displayed digits will reduce slowly until the meter displays [00 cal ]. In the end it will display [End] for one second,
which indicates the end of null-point calibration.
F1.7 Load-point Calibration
[LOAd] Loading weights
Load weights on the weighing platform to ensure that 10% of full-scale value ≤ weight of weights ≤ full-scale value, and then press
the key to start the next step.
[000000] Entering the same weight value as that of the loaded weights.
Entering the same weight value as that of the loaded weights, please press the
meter will display [ ]. After that, the displayed digits will reduce slowly until the meter displays [ ]. In the end it will display [ ] for one
second, which indicates the end of null-point calibration.
F1.8 Automatic Null Tracking
Selectable parameters: OFF, 1 d, 2 d, 3 d (default value)
F1.9 Automatic Reset Range at Startup
Selectable parameters: OFF, 2 %, 10 %, 20 % (default value)
12
button on the operating panel in the state of normal weighing.
0.0 ---- 1 decimal place
0.00 ---- 2 decimal places
0.000 ---- 3 decimal places (default value)
0.0000 ---- 4 decimal places
1 ---- lb
USER'S MANUAL ARX
key and the meter will dis-
key after the scale becomes stable, and the
