1.Release the left side of two water
couplers on the front left corner at the
bottom of appliance : press and hold
in the collar as shown and remove the
water pipe .( Fig .11).
2.Undo the hinge cover screw and
remove the cover ( Fig .12). When re-
moving the freezer door , disconnect all
wires except for the grounding wire .
3. Undo the screws holding the upper
hinge in position and then remove the
hinge(Fig.13).
4. Lift the door to remove it (Fig.14).
When removing the freezer door, Iift
it high enough to pull out the water
connection from the bottom of the
appliance.
5. Refit the door by reversing the re-
moval steps. Ensure that the grounding
cable will be fixed by the screw.
6. Refit the water connection .
NOTICE:
The pictures show the removing of the freezer compartment door . For the fridge
door please use the corresponding parts on the other side .
42
Installation
Fridge door
Fig.12
Fig.13
Fig.11
Fig.14
