EN
Step 3 Install The Front Wheel
A) Put the bike upside down.
B) Loose the nut to remove the temporary protected bar.
C) Insert the wheel between the fork blades so that the axle can seat firmly at the fork dropouts (the
slots at the tip of the fork blades).
D) Put the gaskets on it and tighten the nuts.
Note: if the lever cannot be pushed all the way to a position parallel to the fork blade, return the lever to the
OPEN position. Then turn the tension adjusting nut counterclockwise and make a one-quarter turn, and try
tightening the lever again.
Step 4 Install The Front Light
A) Place the front light with the fork brace.
B) Secure the light by tightening up the bolt.
C) Connect the light cable with the bike cable.
