LIMIT 1180-R Bedienungsanleitung Seite 7

1180-RH/GH: Main unit, small tripod, magnetic wall bracket, target plate, manual, batteries, charger and USB
cable, hard case.
Optional accessories: Laser line detector, clamp, 5/8" tripod adapter, different tripods, laser glasses.
1180-R/1180-G OPERATION INSTRUCTIONS
1. Self-levelling mode
1.1 Turn on the laser and unlock the pendulum by sliding the switch to
is now on. The LED indicator turns green. Press H to turn the horizontal laser line ON/OFF.
1.2 Press V once to turn on 360° side vertical laser line, twice to turn on 360° front vertical laser line.
1.3 Press V three times to turn on both vertical laser lines, four times to turn off both vertical laser lines.
1.4 The laser lines start blinking and a buzzer start sounding if the laser is out of self-levelling range 3° ± 1°.
1.5 Press button to turn on pulse mode, the pulse LED indicator turns blue. This enables to use the optional
detector but makes the laser beam a bit weaker.
1.6 Press button to turn off pulse mode, the pulse LED indicator will turn off. This makes the laser beam
stronger.
2. Manual mode
2.1 When the power is off, press and hold
indicator turns red.
2.2 Press H and V to turn ON/OFF the horizontal and vertical lines.
position. The horizontal 360° laser line
button for 3 seconds to launch the manual mode, the
GB
LED
5
