LIMIT 1180-R Bedienungsanleitung Seite 5

SPECIFICATIONS
Model No
Wavelength
Working distance
Self-levelling range
Leveling time
Laser safety class
Horizontal accuracy
Vertical accuracy
Operating temperature
Housing
Thread
Power supply
Charger output
Operating time
Storage temperature
Size
Net weight
POSITIONS
1. Front vertical laser beam
2. Horizontal laser beam
3. Battery capacity indicator
4. Type-C charging port
5. Lithium battery 3.7 V 5200 mAh
6. Control panel
7. Side vertical laser beam
8. Power OFF / Lock switch
9. Power ON / Unlock switch
10. 1/4" threaded mounting port
1180-R
638 ± 5 nm
Up to 20 m (radius) or up to
50 m (radius) with detector
±3 mm / 10 m
±3 mm / 10 m
-10°C ~ 50°C
3.7 V 5200 mAh Li-ion battery
12 h (all lines on)
-20°C ~ 70°C
90 × 125 × 122 mm
1
1180-G
520 ± 10 nm
Up to 30 m (radius) or up to
50 m (radius) with detector
3° ± 1°
3 seconds
Class 2
IP54
1/4"
5 V 1 A
8 h (all lines on)
545 g
2
6
3
4
5
GB
3
