2. DELIVERY SCOPE

CHAA250EVC
Primary unit with
Control Board

3. TOOLS NEEDED

4. OVERVIEW OF GATE OPERATOR

6
5
1
3 4
Secondary unit
Post Mounting Gate Mounting
Bracket (2x) Bracket (2x)
Screw and nut Cover (2x)
(4x)
Grommets Remote
(6x) Control (2x)
Hardstops (4x)
Screws + Washers (4x)
13, 14 mm
5
4
4
Pin (2x) Circlip pin (2x)
Strain relief
Screw and
4 x M16
Washer (2x)
2 x M20
Release Key Photocell
(4x)
Installation
Manual
6 mm
1. Motor 1 with control board
2
2. Motor 2
3. Post bracket (concealed)
3
4. Gate bracket
5. Infrared photocells
6. Flashing lamp
