EXPLODED VIEW LIST,
1. Lid
Couvercle
Deckel
2. Lid Handle Assembly
Poignée du couvercle
Deckelgriff
3. Upper Ring
Anneau supérieur
Oberer Ring
1 -
2 -
20-
24-
LISTE DES PIÈCES DE LA VUE ÉCLATÉE,
4. Ring Support
5. Lower Ring
6. Fireplace Bottom
4 -
8-
LISTE ZUR EXPLOSIONSDARSTELLUNG
Support de l'anneau
Ringstrebe
Anneau inférieur
Unterer Ring
Partie inférieure du foyer
Feuerschale
7.
Heat Shield
Protection thermique
Hitzeschutz
8. Leg
Pied
Beine
16-
