GB
Setting of the end positions

4.3. Mechanic requirements

Operating of the SEL Plus drives is possible with normal safety and fixing springs.
Optionally, security springs can also be used (manual setup-mode).
For operating the SES security springs must be used.
If the drive is supposed to move against the stop in the upper end position, a stable
end stop must be installed!
If the drive is set in automatic setup-mode, a limit must be installed for the lower switch-
off position (e.g. windowsill) for the shutter to run against.

4.4. Selection table for settings:

Setup-mode/end positions in operation
4.4.1 Automatic setup-mode
bottom position, top stop/release
4.4.2 Manual setup-mode
bottom position, top position
4.4.3 Manual setup-mode
bottom position, top stop/release
SEL Plus
Stop at top
+ Stop at bottom
Bottom position
+ top position
Bottom position
+ top stop
24
SES
Stop at top
+ Stop at bottom
Bottom position
+ top position
Bottom position
+ top stop
