Schneider Airsystems RF-RMG Original Bedienungsanleitung Seite 6

Table of contents - Part 1
1.1 General information ..................
1.2 Scope of delivery ......................
1.3 Conventional use ......................
1.4 Technical data ..........................
1.5 Components.............................
1.6 Commissioning .........................
1.7 EC Declaration of Conformity ......
The specified illustrations appear at the be-
ginning of the Operating Instructions.
1.1 General information
Observe the safety instructions!
Read the Instruction Manual!
1.4 Technical data
Max. permissible pressure
Recomm. hose diameter (interior) with L= 10 m
Overall dimensions (without hose) width x depth x height
Weight RF -RMG
Weight RF - RMG "calibrated"
Weight RF - RMG-K
Weight RMG-K "calibrated"
Weight RMG-M "calibrated"
1.5 Components
01 Plug nipple
02 Trigger lever
04 Pressure gauge
05 Straight valve connector
06 Rocker arm connector
07 Double-sided valve connector
08 Hanger hook
1.6 Commissioning
Note: Read and memorise part 2 of the
instruction manual!
Note: Read and memorise part 2 of the
instruction manual!
3
Subject to technical modifications. Illustra-
3 tions may deviate from the original.
3
1.2 Scope of delivery
3
– Tyre pressure gauge (1)
3
– Instruction manual
3
1.3 Conventional use
4
The tyre pressure gauges are suitable for fill-
ing and setting of air-filled tyres using com-
pressed air or nitrogen.
Any other type of use is considered contrary
to the intended use.
RF-RMG
12 bar
9 mm
280 x 145 x 95 mm
0,90 kg
0,95 kg
0,70 kg
0,80 kg
0,90 kg
GB
I/ 3
