ENGLISH
Cautions
• Do not tear the bag until you use the filters because
they are in the plastic bag to maintain their
performance of dust collection and deodorization.
• Be sure to unplug the power cord of air purifer
from the wall outlet.
• If you push the front panel, the main unit will be
broken.
• Do not loosen the screws which hold the fan guards.
For understanding the product
Some odor ingredients absorbed by the filters may become separated and may be discharged
through the air outlet and result in additional odor.
Depending on the usage environment, the air outlet odor may become strong after several months.
In this case, purchase an exchange filter FZ-80SEF of the option goods, and replace the filters.
1
Remove the filters
1
Remove the front panel.
Loosen the two screws at the top left and right of
the front panel using a phillips (+) screwdriver, then
remove the front panel.
CAUTION
If the front panel is removed after loosing the
screws, the front panel may fall, and injure
someone or some parts may be broken.
2
Extract the handles at the top and bot-
tom of the filter frame, pull them out,
and remove the filter frame from the
main unit.
NOTE
Two filters (top and bottom) are attached to the
filter frame. After removal, lay the filter frame flat
with the handles facing upwards, and replace the
filters.
3
Unhook the four tabs on the pre-filter,
and remove the filter fixers. (Two each
top and bottom)
4
Extract the deodorizing filter (black
(back: white)) and HEPA filter (white).
(One each top and bottom)
Front panel
Tabs (X4)
Filter fixers
Deodorizing filter (Front: black)
Microbial control filter (Back: white)
HEPA filter
E-1
Fan guards
Phillips screws
Handle
Pre-filter
Filter frame
