DESCRIPTION
A Pusher
B Feeding tube
C Pressing screw
D Filter
E Rubber scraper
F Pulp lever control
G Bowl
H Dry residue exit
I Juice exit
DESCRIPTION
1 Soft fruits and vegetables
program touch button
2 Ice-cream program touch
button
3 Reverse function touch button
4 Hard fruits and vegetables
program touch button
122
J Anti-drip
K Motor unit
L Gear
M Electronic display
N Cleaning brush
O Ice cream filter
P Pulp Collector
Q Juice jug
R On The Go Bottle
5 Jam and Puree program touch
button
6 EasyClean function touch
button
7 ON/OFF button
