WS-400 EVO | LS-400 Entech
Before use, adjustment or maintenance, it is important
to read this instruction manual very carefully. This ma-
nual must be stored in a safe place for any future reference.
This Anest IWATA spray guns kit complies
to ATEX regulations 94/9/EC, protection level:
II 2 G X Suitable for using Zones 1 and 2.
X marking: Any static electricity discharge from the spray gun is to be diverted
to the ground via the conductive air hose as stipulated.
ALWAYS observe WARNINGS and CAUTIONS in this
instruction manual.
Symbol WARNING Hazard level
WARNING Potentially hazardous
situation
Potentially hazardous
CAUTION
situation
IMPORTANT Potentially hazardous
situation

1. TECHNICAL SPECIFICATIONS

Max. working air pressure:
Weight g (lbs): (without cup)
Noise level (LAeqT)*:
Air Connection
Fluid Connection
Max. Temperature range: Atmosphere 5 ~ 40 °C / Air-Fluid 5 ~ 43 °C
* Measuring point: 1m backwards from gun, 1.6m height.

2. SAFETY WARNING

FIRE AND EXPLOSION
1. Never use the following HALOGENATED HYDROCARBON SOLVENTS:
which can cause cracks or dissolution of gun body (aluminium) due to
chemical reaction. UNSUITABLE SOLVENTS: methyl chloride, dichloromethane,
1.2-dichloroethane, carbon tetrachloride, trichloroethylene,
1.1.1-trichloroethane
2. Sparks and open flames are strictly prohibited. Paints can be highly
flammable and can cause fire. Do not expose to open flames, electrical
goods, cigarettes etc.
3. Securely ground spray gun using conductive air hose. (Less than1MΩ)
Always ensure that the spray gun is earthed correctly.
PROTECTION OF HUMAN BODY
1. Use in a well-ventilated site, using a spray booth.
Poor ventilation can cause organic solvent poisoning and fire.
2. Always wear protective gear (safety glasses, mask, gloves) to avoid
inflammation of eyes and skin.
In case of any physical discomfort, immediately seek medical advice.
3. Wear earplugs if necessary.
Noise level can exceed 80 dB(A), depending on operating conditions and
painting site.
4. Pulling the trigger many times during operation, may cause carpal
tunnel syndrome. Always rest, in case of tiredness.
All manuals and user guides at all-guides.com
IMPROPER USE
1. Never point gun towards people or animals.
2. Never exceed maximum working pressure or maximum operating
3. Always release air and fluid pressure before cleaning, disassembling
4. Tip of fluid needle set has a sharp point.
5. Never use this gun to spray foods or chemicals. Otherwise, foreign sub-
Consequence
6. Never alter this spray gun, to avoid insufficient performance and damage.
Death or serious injury
7. If something goes wrong, immediately stop operation and find the cause.
Minor to moderate injury
Property damage
8. Do not enter working areas, where robots, reciprocators, etc. are used,

3. HOW TO CONNECT

7.0 bar (100 PSI)
-
475 (1.05)
-
75.8 dB(A)
G1/4" M
-
G1/4" F
1. Firmly connect an air hose to air nipple 1/4"(4-2).
2. Firmly connect a suitable cup to fluid nipple (4-1).
3. Flush fluid passages with a compatible solvent.
4. Pour paint into container, test spray, adjust fluid output and pattern width.

4. HOW TO OPERATE

_ Suggested atomizing air pressure is 1.5 to 2.5 bar (21 to 36 PSI).
_ Recommended paint viscosity differs according to paint property and
_ Set the spray distance from the gun to the work piece, as near as possi-
_ The gun should be held so that it is perpendicular to the surface of the

5. MAINTENANCE AND INSPECTION

CAUTION
- Never use spare parts that are not Anest Iwata originals.
- Never damage fluid nozzle tip, fluid needle or air cap holes.
- Never immerse the spray gun completely in liquids such as thinner.
5.1 MANUAL CLEANING PROCEDURE
Temperature
or servicing. Otherwise, remaining pressure can cause bodily injury due to
improper operation or scattering of cleaning liquid.
Do not touch the tip during maintenance to avoid accidents.
stance, could cause corrosion of fluid passages which could adversely affect
health.
Do not use again, until you have solved the problem.
until they have been turned off. Otherwise, they could cause injury.
CAUTION
Use clean air filtered through air dryer and air filter.
When using this gun for the first time after purchase, adjust fluid needle
packing set, spray cleaner to clean fluid passages and remove rust pre-
ventive oil.
Firmly fix hose or container to spray gun, to avoid disconnection of hose
or container, that can cause bodily injury.
painting conditions. 14 to 25 sec. / Ford cup#4 is recommended.
ble within the range of 130-200 mm.
workpiece at all times. Then, the gun should move in a straight and hori-
zontal line. Arcing the gun causes uneven painting.
Before carrying out maintenance and inspection ALWAYS
observe warning indications.
The fluid passages of the gun, must be cleaned thoroughly
after each use, especially after use with bi-component paints.
Incomplete cleaning can cause defective pattern shape.
GB
3
