6. Operation
Install the equipment on a solid and level surface.
n
Remove the ventilation screw (7).
n
Unscrew the coarse filter screw (6) and remove
n
the coarse filter (8) as shown in Figure 2. Now
you can fill the pump housing with water via the
coarse filter screw (6). Filling the intake line
accelerates the intake process.
Assemble in reverse order.
n
Open the discharge line.
n
Connect the mains cable.
n
Switch on the equipment with the power switch
n
(3) - water can be suctioned in for up to 5 minutes
(maximum suction height).
After finishing the work, switch off the equipment
n
with the power switch (3).

7. Replacing the power cable

If the power cable for this equipment is damaged, it
must be replaced by the manufacturer or its after-
sales service or similarly trained personnel to avoid
danger.
8. Cleaning, maintenance and
ordering of spare parts
The equipment is almost completely maintenance
free. In order to ensure a long service life, however,
we recommend that you regularly check and care for
the product.
Important!
The equipment must be disconnected from the power
supply (pull the power plug) prior to performing any
maintenance.
8.1 Servicing
If the equipment becomes clogged, connect the
n
discharge line to the water line and disconnect
the suction hose. Open the water line. Switch on
the equipment several times for approx.
two seconds. This should resolve the majority of
clog-related problems.
Replacing the mains cable: Important:
n
Disconnect the equipment from the power
supply! A defective mains cable may only be
replaced by a qualified electrician.
There are no parts inside the equipment which
n
require additional maintenance.
8.2 Cleaning the coarse filter insert
Clean the coarse filter insert at regular intervals,
n
and replace it if necessary.
Remove the coarse filter screw (6) and coarse
n
filter (8) (Figure 2).
Disassemble the coarse filter insert as shown in
n
Figure 3.
Do not use abrasive cleaning agents or petrol to
n
clean the coarse filter.
Clean the coarse filter by tapping it on a flat
n
surface. In cases of stubborn dirt first clean with
soapy water, then rinse with clear water and air-
dry.
Assemble in reverse order.
n
8.3 Storage
If the pump is not going to be used for a long time
n
or has to be removed for the winter months, rinse
it out with water, empty it completely and allow it
to dry.
The equipment must be completely drained
n
before it is subjected to frost.
After long stoppages, make sure the rotor turns
n
correctly by briefly switching the pump on and off.
8.4 Ordering replacement parts:
Please quote the following data when ordering
replacement parts:
Type of machine
n
Article number of the machine
n
Identification number of the machine
n
Replacement part number of the part required
n
For our latest prices and information please go to
www.isc-gmbh.info

9. Disposal and recycling

The unit is supplied in packaging to prevent its being
damaged in transit. This packaging is raw material
and can therefore be reused or can be returned to the
raw material system.
The unit and its accessories are made of various
types of material, such as metal and plastic. Defective
components must be disposed of as special waste.
Ask your dealer or your local council.
