Becker CentronicPLUS EC548 PLUS Montage- Und Betriebsanleitung Seite 23

16-channel hand-held transmitter
Channel
Channel 1 - 4
Channel 5 - 8
Channel 9 - 12
Channel 13 - 16
Channel 1 - 16
manual / automatic
You can display and select the "Manual" or "Automatic" setting by pressing the
STOP button. Only manual drive commands and emergency signals can be
performed with the "Manual" setting. In addition, automatic drive commands
are also performed in the "Automatic" setting. The automatic functions are not
interrupted if a manual drive command is carried out when in automatic mode.
3s
5s
Group
Group 1
Group 2
Group 3
Group 4
Group all
(central command)
Press the STOP button for 3 seconds to display
the current status.
Automatic
mode:
Manual mode: The LED ring lights up red.
Different
modes:
You can toggle between manual and automatic
mode by pressing the STOP button for 5 seconds.
Colour
LED ring
green
red
yellow
light blue
White
The LED ring lights up green.
The LED ring lights up yellow.
23 - en
