Spezifikationen
modbus port set <ip_port>
modbus port show
port
port {port_num} state set {OFF=0|ON=1}
port {port_num} state show
port all state set "{port_list}" {OFF=0|ON=1}
port all state {MODE0=0|MODE1=1|MODE2=2}
show
port {port_num} reset
port {port_num} toggle
port {port_num} batch set {OFF=0|ON=1} wait
{num_secs} {OFF=0|ON=1}
port {port_num} batch cancel
port {port_num} label set "{name}"
port {port_num} label show
port {port_num} initstate coldstart set {OFF=0|
ON=1|REMEMBER=2}
port {port_num} initstate coldstart show
port {port_num} initstate delay set {num}
port {port_num} initstate delay show
port {port_num} repowerdelay set {num}
port {port_num} repowerdelay show
port {port_num} resettime set {num}
port {port_num} resettime show
port {port_num} watchdog enabled set {OFF=0|
ON=1}
port {port_num} watchdog enabled show
port {port_num} watchdog mode set {OFF=0|
PORT_RESET=1|IP_MS=2|IP_MS_INV=3}
port {port_num} watchdog mode show
port {port_num} watchdog type set {WD_ICMP=0|
WD_TCP=1}
port {port_num} watchdog type show
port {port_num} watchdog host set "{dns_name}" sets port watchdog host target
port {port_num} watchdog host show
port {port_num} watchdog port set {ip_port}
port {port_num} watchdog port show
port {port_num} watchdog pinginterval set {num}
port {port_num} watchdog pinginterval show
port {port_num} watchdog pingretries set {num}
port {port_num} watchdog pingretries show
port {port_num} watchdog retrybooting set
{OFF=0|ON=1}
port {port_num} watchdog retrybooting show
port {port_num} watchdog bootretries set {num}
port {port_num} watchdog bootretries show
portsensor
portsensor all {field_list} show
portsensor {port_num} {energy_sensor} value
show
portsensor {port_num} counter reset
portsensor {port_num} {energy_sensor} events set
{OFF=0|ON=1}
portsensor {port_num} {energy_sensor} events
show
portsensor {port_num} {energy_sensor} events ty-
pe set
"{EVT_SYSLOG=0,EVT_SNMP=1,EVT_EMAIL=2
,EVT_SMS=3,EVT_GSMEMAIL=4,EVT_BEEPER
=5}"
portsensor {port_num} {energy_sensor} events ty-
pe show
portsensor {port_num} {energy_sensor} maxval
set {num}
portsensor {port_num} {energy_sensor} maxval
show
portsensor {port_num} {energy_sensor} minval set
{num}
portsensor {port_num} {energy_sensor} minval
show
portsensor {port_num} {energy_sensor} hyst set
{num}
portsensor {port_num} {energy_sensor} hyst show shows hysterese value for sensor
Expert Power Control 8041/8045
sets Modbus TCP port
shows Modbus TCP port
enters cmd group "port"
sets port to new state
shows port state
sets several ports in one cmd - e.g. port all state
set "1,3,5" 1
shows all port states in 3 different view modes
start reset sequence for port
toggles port
starts batch mode for port
cancels batch mode
sets port label name
shows port label name
sets port coldstart initialization
shows port coldstart initialization
sets port init delay
shows port init delay
sets port repower delay
shows port repower delay
sets port reset duration
shows port reset duration
sets port watchdog to on/off
shows port watchdog state
sets port watchdog mode
shows port watchdog mode
sets port watchdog type
shows port watchdog type
shows port watchdog host target
sets port watchdog TCP port
shows port watchdog TCP port
sets port watchdog ping interval
shows port watchdog ping interval
sets port watchdog ping retries
shows port watchdog ping retries
sets port watchdog retry booting to on/off
shows port watchdog retry booting state
sets port watchdog retry boot timeout
hows port watchdog retry boot timeout
enters cmd group "portsensor"
shows energy sensors according field list of all
port sensors
shows energy sensor of given port
resets energy metering counter
enables sensor events on/off
shows if sensor events are enabled
enables different event types
shows what event types are enabled
sets maximum value for sensor
shows maximum value for sensor
sets minimum value for sensor
shows minimum value for sensor
sets hysterese value for sensor
4
5
5
76
