Gude Expert Power Control 8041 Serie Anleitung Seite 57

Spezifikationen
epc8045TrapCtrl
epc8045TrapIPIndex
epc8045TrapAddr
epc8045portNumber
epc8045PortIndex
epc8045PortName
epc8045PortState
epc8045PortSwitchCount
epc8045PortStartupMode
epc8045PortStartupDelay
epc8045PortRepowerTime
epc8045Buzzer
epc8045ActivePowerChan
epc8045PowerIndex
epc8045ChanStatus
epc8045AbsEnergyActive
epc8045PowerActive
epc8045Current
epc8045Voltage
epc8045Frequency
epc8045PowerFactor
epc8045Pangle
epc8045PowerApparent
epc8045PowerReactive
epc8045AbsEnergyReactive
epc8045AbsEnergyActiveResetta-
ble
epc8045AbsEnergyReactiveReset-
table
epc8045ResetTime
epc8045ForwEnergyActive
epc8045ForwEnergyReactive
epc8045ForwEnergyActiveReset-
table
epc8045ForwEnergyReactiveRe-
settable
epc8045RevEnergyActive
57
Expert Power Control 8041/8045
Description
.87.1.1.1.1.0
0 = off 1 = Ver. 1 2 = Ver. 2c 3 = Ver. 3
.87.1.1.1.2.1.1.x
A unique value, greater than zero, for each receiver slot.
.87.1.1.1.2.1.2.x
DNS name or IP address specifying one Trap receiver slot. A port can
optionally be specified: 'name:port' An empty string disables this slot.
.87.1.3.1.1.0
The number of Relay Ports
.87.1.3.1.2.1.1.x
A unique value, greater than zero, for each Relay Port.
.87.1.3.1.2.1.2.x
A textual string containing name of a Relay Port.
.87.1.3.1.2.1.3.x
current state of a Relay Port
.87.1.3.1.2.1.4.x
The total number of switch actions ocurred on a Relay Port. Does not
count switch commands which will not switch the ralay state, so just real
relay switches are displayed here.
.87.1.3.1.2.1.5.x
set Mode of startup sequence (off, on , remember last state)
.87.1.3.1.2.1.6.x
Delay in sec for startup action
.87.1.3.1.2.1.7.x
Delay in sec for repower port after switching off
.87.1.3.10.0
turn Buzzer on and off
.87.1.5.1.1.0
Number of suppported Power Channels.
.87.1.5.1.2.1.1.x
Index of Power Channel entries
.87.1.5.1.2.1.2.x
0 = data not active, 1 = data valid
.87.1.5.1.2.1.3.x
Absolute Active Energy counter.
.87.1.5.1.2.1.4.x
Active Power
.87.1.5.1.2.1.5.x
Actual Curent on Power Channel.
.87.1.5.1.2.1.6.x
Actual Voltage on Power Channel
.87.1.5.1.2.1.7.x
Frequency of Power Channel
.87.1.5.1.2.1.8.x
Power Factor of Channel between -1.0 and 1.00
.87.1.5.1.2.1.9.x
Phase Angle between Voltage and L Line Current between -180.0 and
180.0
.87.1.5.1.2.1.10.x
L Line Mean Apparent Power
.87.1.5.1.2.1.11.x
L Line Mean Reactive Power
.87.1.5.1.2.1.12.x
Absolute Reactive Energy counter.
.87.1.5.1.2.1.13.x
Resettable Absolute Active Energy counter. Writing '0' resets all resetta-
ble counter.
.87.1.5.1.2.1.14.x
Resettable Absolute Reactive Energy counter.
.87.1.5.1.2.1.15.x
Time in seconds since last Energy Counter reset.
.87.1.5.1.2.1.16.x
Forward Active Energy counter.
.87.1.5.1.2.1.17.x
Forward Reactive Energy counter.
.87.1.5.1.2.1.18.x
Resettable Forward Active Energy counter.
.87.1.5.1.2.1.19.x
Resettable Forward Reactive Energy counter.
.87.1.5.1.2.1.20.x
Reverse Active Energy counter.
Integer32 RW
Integer32 RO
OCTETS RW
Integer32 RO
Integer32 RO
OCTETS RW
INTEGER RW
Integer32 RO
INTEGER RW
Integer32 RW
Integer32 RW
Integer32 RW
Unsigned32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Integer32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Integer32 RO
Gauge32 RO
Gauge32 RW
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
Gauge32 RO
