Pepperl+Fuchs IDENTControl Compact IC-KP2-2HB18-2V1 Handbuch Seite 40

IC-KP2-2HB18-2V1
Befehle
Lesebefehl single mit geteilten Daten
ID command execution request (RYn4)
Abbildung 7.6
Lesebefehl enhanced ohne geteilte Daten
ID command execution request (RYn4)
Abbildung 7.7
40
writing cmd to RWw
PLC program
ID BUSY (RXn3)
ID division data request (RXn7)
ID division data complete (RYn7)
ID command complete (RXn4)
ID data ack (RYn3)
ID in zone contact (RXn2)
Tag communication
ID error occurrence (RXn5)
writing cmd
PLC program
ID BUSY (RXn3)
ID division data request (RXn7)
ID division data complete (RYn7)
ID command complete (RXn4)
ID data ack (RYn3)
ID in zone contact (RXn2)
Tag communication
ID error occurrence (RXn5)
reading response
part 1 from RWr
reading response
to RWw
from RWr
reading response
part 2 from RWr
reading response
from RWr
