SmartStor NS4300N Quick Start Guide
Figure 1. SmartStor NS4300N Front View
Note: This SmartStor is shown without the front door.
Figure 2. SmartStor NS4300N Rear View
4
Disk Drive
Drive Carrier
Drive Status
LED
Drive Activity
LED
Power Button
System Status
LED
Ethernet
Activity LED
One Touch
Backup Button
Disk Drive
Cooling Fan
RJ45 Network
Connection
USB
Connections
Power
Supply Fan
Power
Connection
