EXPANDED VIEW

Connection of Control Part
9
8
Connection of Ignition Part
Thermocouple
Electrode
1
2
3
4
5
Burner Tube
10 / 112
1, Knob
2, Control Panel
3, Corrugated Pipe
4, Valve
5, Thermocouple
6, Igniter
7, Ground Wire
8, Electrode
9, Valve Inlet Fitting
