Xiaomi Mesh System AX3000 Benutzerhandbuch Seite 9

Method 3:
1. Reset the satellite router to the factory se ings, and then
power it on. Wait for the satellite router's system indicator to
turn blue or white (the indicator's color depends on the
specific model).
2. Connect the network cable to the satellite router's WAN port
and the main router's LAN port, then the Internet indicator
will begin to blink quickly (two blinks per second), indicating
the Mesh networking starts.
3. When the Internet indicator of the satellite router remains lit,
the Mesh networking is successfully completed.
Satellite Router
WAN
Port
LAN
Port
Main Router
7
Internet
