How to Use

Read this manual carefully before use, and retain it for
future reference.
Connecting the Main Router
Power on either of the routers, then use the included
network cable to connect the blue WAN port on the back of
the router to the LAN port of the broadband modem.
Connect to a
Power Socket
Connect to the Power Port
*Broadband modem is provided by the broadband operator. If
it is not available, you can connect the network cable to the
router and the Internet wall socket, or directly connect the
indoor network cable to the router's WAN port.
WAN Port
1
Broadband Modem
(Provided by Broadband Operator)
Internet Wall Socket
LAN Port
Or
