UNILITE RL-5250 Kurzanleitung

FEATURES
• Ultra bright 5250 Lumen 50W 6500k 160 x SMD LEDs
• Dual Power - rechargeable battery and mains powered
• 360° and 180° Lighting modes
• Ultra tough nylon polymer & polycarbonate construction
• Milky diffuser lens for even light dispersion
• Stainless steel carry handle on the top
• Concealed ultra tough hanging hook in the base
• 1/4" Screw hole in the base for attaching to tripods
• IP65 dust & water proof
• IK07 shock resistant
• High power 11.1v 5200mAh Li-ion battery
• 3 Battery level and charging indicator LEDs
• Mains 15V 1.5A multi-country charger/power lead included
• 3½ hours charge time
BATTERY - 11.1v 5200mAh Rechargeable Li-ion Battery
WEIGHT - 1820g
DIMENSIONS - 157.5 x H 285.6 mm
ADVICE & IMPORTANT INFORMATION!
LEDs will become hot when switched on; do not touch and never place face down
on any surface – risk of fire! Even once the lamp has been switched off, DO NOT let
the lens touch any surfaces as the LEDs/Lens can stay hot/warm for a while.
Do not look directly at the LEDs. Do not operate in intense sunlight or extreme
temperature conditions (below -10°C or above 40°C).
Do not use the device if there is any visible damage to the housing, charge port,
switches or charger. Take care when using the charger, always check for any damage
first. Only use the charger provided. DO NOT exceed 15V 1.5A charging input or
damage may occur to the battery. Never remove the charger from the mains power
socket with wet hands, and do not attempt to remove by pulling the cord, always
grasp the plug unit.
The rechargeable battery will reach full performance after a few complete charging
and discharging cycles.
To keep the rechargeable battery in optimum condition, it should be recharged
every 3-6 months, especially if it is not being used for a long period of time. Always
fully charge batteries before storage.
Always protect lithium batteries from heat, intense sunlight, fire, water and moisture
– danger of explosion!
If a battery is damaged, fluids can leak out. AVOID contact as this can lead to skin
irritation and/or burns. If skin contact occurs, rinse thoroughly with water. If irritation
www.unilite.co.uk
ANSI F L 1 Standard
360° LIGHT - ECO
360° LIGHT - LOW
360° LIGHT - MID
360° LIGHT - HIGH
180° LIGHT - LOW
180° LIGHT - MID
180° LIGHT - HIGH
OPERATION
ON/OFF SWITCH - 360° Lighting > 180° Lighting > Off
BRIGHTNESS SWITCH - 360° Lighting:- Eco > Low > Mid > High
180° Lighting:- Low > Mid > High
MEMORY FUNCTION:- If left ON in any mode for 5 seconds or more,
the next press will turn OFF. Next press ON will return to that last mode
used.
CHARGING
Mains powered 15V 1.5A charger/power lead included, with UK/EU/
AU/US plug adaptors included.
Only use the charger provided otherwise damage may occur and
warranty will be void.
1. Lift the charging port cover on the back of the lamp.
2. Plug the DC end of the cable into the charge port.
3. Plug the AC/DC plug into a mains AC plug socket.
4. The 3 x indicator LEDs will illuminate and flash to show charging
status. Once fully charged, all 3 indicators will illuminate continually.
5. If the battery indicators do not illuminate, remove the charger and
try again.
6. Charge Time: 3 ½ hours
The intelligent battery and charging lead means the light can be used
whilst charging. Even with a fully charged battery, the charging lead
can be used as a constant power supply.
PLEASE NOTE: When lamp is charging/plugged in, the 360° Lighting
in HIGH mode is not available.
Fully charge before first use.
*Warranty void if not used with the charger provided*
persists, seek medical advice. Seek immediate medical assistance if lithium battery
fluid comes into contact with the eyes.
Children under 12 years of age should only use the product under adult supervision.
Do not open, disassemble or attempt to modify the product; this will void the
warranty and can be dangerous. Improper use or modification is not covered under
the warranty.
Take care not to let the lens come into contact with hard/sharp objects, damage/
scratches to the lenses will affect light output.
This product is water resistant to IPX5 - DO NOT SUBMERGE. If the product has
been subjected to excessive water the warranty may be void.
This product has a 1 year standard warranty (or extended to 2 years once registered
online at WWW.UNILITE.CO.UK/WARRANTY) against manufacturing faults and
defects, commencing on the date of purchase. It does not cover normal wear and
tear, modifications, accidental damage or poor maintenance. Unilite warranties do
not cover battery leaks or the use of incorrect chargers and cables that can damage
batteries.
Do not dispose of this device in normal household waste. It must be disposed of via
an authorised electrical appliance disposal centre or at your local waste disposal
unit.
Please re-use or recycle packaging responsibly where possible.
Keep these instructions for future reference or for subsequent possessors.
RL-5250
500
10 M 16 H
Lumens
1100
21 M 8 H
Lumens
2200
34 M 4
Lumens
5250
44 M 2 H
Lumens
500
10 M 16 H
Lumens
1100
21 M 8 H
Lumens
2200
34 M 4
Lumens
H
H
