RDE50.1
Operating Instructions
Programmable thermostat for heating system
RDE50.1 is a programmable thermostats that allows
the user to improve the comfort at home and, at the
same time, also allows to reduce the energy
consumption by a weekly selection of:
• The periods when you want to maintain a higher
temperature ( Comfort mode)
• The periods when temperature can be lower
(

Economy mode)

Set time and day
To set the time and day, press the
1)
ok
Press and the time will flash for setting.
2)
3) Press the + or – button to adjust the time. Press
The dot under the days will flash, press the + or – button to scroll the dot until it reaches the desired day.
4)
ok
Press to confirm.
esc
Press to exit or wait for 15 sec and the system exits automatically.
5)
Change the room temperature setpoint
Energy saving tips without sacrificing comfort
Air out rooms for short periods of time only, and do so properly with the windows wide open.
•
Set your room temperatures to around 21 °C.
•
As a general calculation rule, the reduction of 1 º C in the temperature setpoint produces a 7% energy saving.
•
Selection of operation modes (Comfort mode
The thermostat provides the option of selecting Comfort mode, Economy mode and Auto mode. The changeover
between the Comfort and Economy modes can be made either manually via operating
automatically as per the 7-day time programs in Auto mode.
Comfort mode corresponds to occupancy periods where you want to maintain the Comfort temperature.
Economy mode corresponds to no occupancy periods and also period when you want to maintain the Economy
temperature, e.g., during the nights.
Energy saving tips without sacrificing comfort
• Use Auto mode during the heating period, and set the time programs according to your normal habits at home.
• Use Economy mode or Holiday mode during long periods of no occupancy and during summer period.
mode
• Press the button to switch between Comfort
ok
• Press to confirm the selected mode or wait 5 seconds and the system exits automatically.
Holiday mode setting
In the Holiday mode, you may set the thermostat to run at a constant temperature setpoint during your absent days.
To activate the holiday mode, press the
1)
Press + or – to adjust the temperature setpoint for Holiday mode. Press
2)
Next press + or – to adjust the number of days that you are out for holiday (Note: 0 = Holiday Mode Off).
3)
ok
Press to confirm.
4)
5) Once the holiday is activated, the countdown of remaining days is shown on the screen.
*Note: Holiday mode can be aborted at any time by pressing
Siemens Smart Infrastructure
2022-03-29
Push buttons:




Display



set
button until
You may adjust the room temperature setpoint at any mode:
•
Press the + or – button to adjust the temperature. Press
The temperature can be set from 4...35 °C, with steps of 0.5 º C.
•
Thermostat connects and disconnects the heating to maintain the selected setpoint in
the room.
*Note: In Auto mode, the change is only valid up to the next mode switching time.
Comfort mode is a permanent (24 h) selection of the Comfort setpoint (20 º C). Use
this option when you want to maintain the Comfort temperature permanently without any
time program.
Economy mode is a permanent (24 h) selection of the Economy setpoint (16 º C). Use
this option when you want to maintain the Economy temperature permanently without
any time program, e.g., during the summer period without heating.
Auto mode changes automatically from Comfort mode to Economy mode following
the time schedules prepared for every day of the week.
set
A5W00231886A_AA
Access to:
SET
• Setpoint setting
• Time and day setting
OK Acknowledgment of setting/input
MODE Selection of operating modes:
• Comfort mode
+
Increase value
Low battery
Holiday mode setting
7-Day Timer program
setting
Quit setting mode
Quit saving
Economy mode
Keypad lock activated
is selected.
ok
to confirm.
/ Economy mode
Economy and Auto mode
button until is selected, then press
esc
.
• 7-day timer program setting
• Holiday mode setting
• Economy mode •
-
Increase value

Boiler, pump or heater
activated
Time and day setting
Setpoint setting
Temperature
Time of the day
Day of the week
Time bar
Comfort mode
Auto mode
ok
to confirm.
/ Auto mode )
mode
button or
.
ok
.
ok
to confirm.
A6V13156978_en--_a
Auto mode
