System voltage
12 V
24 V
System voltage
12 V
24 V
NOTE:
The above values are calculated for the standard test condition (STC): solar radiation intensity
1000 W/m2, panel temperature 25°C, AM (air mass) 1.5.
Highest panel type power
The MPPT controller has built in protection from overload and overcurrent. Unfavourable operating
conditions, connection of over powerful solar panels or other conditions, can result in dangerously
high power or charging current. The following four operating situations can occur.
Operating situation 1 (no overload)
The solar panel's actual charging power ≤ rated power of charge controller
Operating situation 2 (no overcurrent)
The solar panel's actual charging current ≤ rated current of charge controller
When the charge controller is working in operating situation 1 or 2 charging takes place with the
current or power the solar panel actually produces and the charge controller traces and utilises the
maximum power of the solar panel.
WARNING!
Even if the power of the solar panel does not exceed the rated power of the charge controller, but
the highest open circuit voltage of the solar panel is higher than 60 V (Tracer **06 AN) respective
100 V (Tracer **10 AN) (at lowest ambient temperature), the charge controller can be damaged.
82
36 cells
U oc < 23 V
Most
Max. Max.
suitable
4 2
4 3
72 cells
U oc < 46 V
Max. Most suitable
2 1
2 1
48 cells
U oc < 31 V U oc < 34 V
Most
Max.
suitable
2 1 2
2 2 2
96 cells
U oc < 62 V
Max. Most suitable
1
1
54 cells 60 cells
U oc < 38 V
Most
Max.
suitable
1 2
2 2
Thin film panel
U oc < 80 V
1 1
1 1
Most
suitable
1
2
1
1
