Inserting the battery into the machine
Fig. B2
Ensure that the exterior of the battery is clean and
dry before connecting to the charger or machine.
• Insert the battery (14) into the base of the
machine.
• Push the battery further forward until it clicks
into place.
Checking the battery charging status
Fig. C
The included battery is delivered in partly charged
condition.
• To check the battery charge status, push the
button (16) on battery shortly.
• The battery has 3 lights indicating the charge
level, the more lights that burn, the more
charge the battery has left.
Charging the battery (with the charger)
Fig. B1
• Plug the charger plug into an electrical outlet
and wait for a while.
• Plug the output of the charger into the round
socket of the battery. The LED indicator on
the battery (14) will lighten up and show the
charging status.
LED indicator (17)
Fig. C
The battery has 1 LED indicator (17) which
indicates the status of the charging process:
LED Charger status
Red Battery charging in progress
Green Battery charging finished, battery fully charged
• After the battery is fully charged remove the
charger plug from the outlet and remove the
battery from the charger.
When the machine is not being used
over a longer period of time it is best to
store the battery in charged condition.
After the battery is fully charged remove the
charger plug from the outlet and remove the
battery from the charger.
• Slide the HEPA filter (12) over the filter
holder(13) as shown in Fig. D.
8
Clean the HEPA filter (12) regularly and
after every heavy use to maintain the
suction power.
• Place the top section (8) on the container (7) as
shown in Fig. E-1.
• Secure the metal locking clamps (5) of the
container to the top section (8) as show in Fig.
E-2.
• Close the metal locking clamps (5) by pushing
them downwards.
• Connect the suction hose (9). For vacuuming
(Fig. F): Connect the suction hose (9) to the
vacuum port (3). For blowing (Fig. G): Connect
the suction hose (9) to the blowing port (4).
• Connect the round nozzle (10) or the crevize
nozzle (11) to the hose (9).
4. OPERATION
Switching the machine on/off
Fig.A
Do not vacuum without a Hepa filter!
• To switch on the vacuum cleaner, move the
On/Off switch (1) forwards (direction ON).
• To switch off the vacuum cleaner, move the
On/Off switch (1) backwards (direction OFF).
Vacuuming
Fig. D, E-1, E-2, F
Clean the HEPA filter (12) regularly and
after every heavy use to maintain the
suction power.
Fine dust, such as dust from cement, soot
and plaster are too fine to be used. Risk
for getting into the motor and damaging it.
1. Switch off (1) the machine and remove the
battery (14).
2. Unlock the metal locking clamps (5) and
remove the top section (8).
3. Before vacuuming, remove all dirt and debris
from the container (7).
4. Fit the filter. Carefully slide the HEPA filter (12)
over the filter holder (13) as shown in Fig. D.
