Dismantling the fan assembly
Take out the fan assembly. Rotate the fan grille counterclockwise until it is
loose, as shown in Fig.
below. Remove the fan grille as per the directions
1
in Fig.
and remove fan blades.
2
1
2
2
Fan assembly
11
12
Fan grille
Fan blades
13
Rear fan cover
6
Installing the rear fan cover
Place the rear fan cover on the motor aligned at the top
Tighten
fan cover knob clockwise to attach the rear fan cover to motor.
5
Installing the fan blades
Align the center hole of fan blades with the motor shaft and push into
position. Tighten the
blade knob counterclockwise to attach fan
4
blades to motor that has the rear fan cover installed.
position.
