Technical Specifications - Johnson Controls SDP2500 Installationsanleitung

Enclosure with UV and weather protection
After some time, outdoor mounted plastics can lose their color and quality. Therefore, all hinged cover enclosures
are made of special white polycarbonate (PC). The light-stable colorants and additives are used to achieve
optimum protection of the polymer while maintaining color stability. The titanium dioxide used is especially
developed for polycarbonate and offers excellent UV protection through the reflection of the entire light spectrum
including the UV component around 340 nm. This effectively counteracts the otherwise occurring photochemical
polymer degradation. The color intensity is preserved for a long time without fading. The material is also resistant
to cold and frost.

Technical Specifications

Models
Power supply
Power consumption
Measuring range pressure
Analogue output
Accuracy pressure
Max. working overpressure
Display
Enclosure
Protection
Cable entry
Connection electrical
Ambient condition
Storage condition
Mounting
Mounting
Before installing the device, please check all pressurized tubes for tightness.
AZ - Automatic Zero-Point Calibration (optional)
Initial Power ON: Once the device is powered up, the Auto-zero reset will be performed multiple times in intervals
shorter than 10mins (contrary to the operational mode). This is to compensate the self-heating of the sensor and
PCB after start up and to provide accurate measurements throughout. After around 30mins, the device goes fully
into operational mode.
Transmitters equipped with the automatic zero-point correction are maintenance-free.
The auto-zero calibration electronically adjusts the transmitter to zero every 10 minutes. The function eliminates
all output signal drifts due to thermal, electronic or mechanical effects. The auto-zero adjustment takes approx. 4
seconds after which the device returns to its normal operation. During the 4 seconds correction phase, the output
and display values will freeze to the last measured value. After the zero-point correction, display values and output
signal go back into live mode.
SDP2500-R8
0..10V
SDP2500-R8-AZ 0..10V, AZ
SDP2500-R8-D 0..10V, with LCD
SDP2500-R8-AZ-D 0..10V, AZ, with LCD
SDP2500-C4-AZ-D 0..10V, AZ, with LCD, Calibration certificate - 0, 250, 500Pa
SDP2500-C5-AZ
0..10V, AZ, Calibration certificate - 0, +500, +1000Pa
SDP2500-C5-AZ-D 0..10V, AZ, with LCD, Calibration certificate - 0, +500, +1000Pa
SDP2500-C6-AZ-D 0..10V, AZ, with LCD, Calibration certificate - 0, +750, +1000Pa
SDP2500-C8-AZ 0..10V, AZ, Calibration certificate - 0, +1250, +2500Pa
15..24 V = (±10%) or 24 V ~ (±10%) SELV
typ. 1,1 W (24 V =) | 1,7 VA (24 V ~)
-100..+100 | 0..+100 | 0..+250 | 0..+500 | 0..+1000 | 0..+1500 |
0..+2000 | 0..+2500 Pa (default)
0..10 V, min. load 10 kΩ
deviation compared to the reference device
measuring range ≤500 Pa: ±5 Pa,
measuring range >500 Pa: ±10 Pa
400 kPa
LCD 37,5x31,6 mm, measured values: Pa
hinged cover enclosure, PC, pure white
(with LCD, transparent cover)
IP54 according to EN 60529, IP65 with bolted cover
M20 for cable max. Ø=8 mm,
seal insert for double cable entry for wire max Ø=6 mm
Terminal block, max. 1,5 mm²
-10..+50 °C, max. 85% rH, short term condensation
-30..+70 °C, max. 85% rH, short term condensation
Screw-mounted onto flat surface, prepared for mounting on DIN
rail TS35 (35x7,5 mm) according to EN 60715
SDP2500 Differential pressure transmitter
