SDP2500 Differential Pressure Transmitter
Installation Instructions
EN DE
Application
Differential pressure transmitter with 8 selectable ranges and
0..10 V output. For monitoring of differential pressure in air and
other non-flammable and non-aggressive gases. Possible
applications: Monitoring of air filters, fans, industrial cooling air
cycles as well as overheating protection, control of air and fire
damper actuators. Screw-mounted onto flat surface, prepared
for mounting on DIN rail TS35 (35x7,5 mm) according to EN
60715.
Solution
Security Advice
The installation and assembly of electrical equipment should only be performed by authorized
personnel.
The product should only be used for the intended application. Unauthorised modifications are
prohibited! The product must not be used in relation with any equipment that in case of a failure may
threaten, directly or indirectly, human health or life or result in danger to human beings, animals or
assets. Ensure all power is disconnected before installing. Do not connect to live/operating equipment.
Please comply with
• Local laws, health & safety regulations, technical standards and regulations
Condition of the device at the time of installation, to ensure safe installation
•
• This data sheet and installation manual
Before mounting, commissioning and operation make sure that the right pressure gauge has been
selected in terms of measuring range, design and, due to the specific measuring conditions, the suitable
wetted medium. Only install and maintain pressure gauges by qualified personnel authorized by the
plant operator. Failure to comply with applicable regulations may result in serious personal injury
and / or property damage.
Notes on Disposal
As a component of a large-scale fixed installation, JCI products are intended to be used permanently
as part of a building or a structure at a pre-defined and dedicated location, hence the Waste Electrical
and Electronic Act (WEEE) is not applicable. However, most of the products may contain valuable
materials that should be recycled and not disposed of as domestic waste. Please note the relevant
regulations for local disposal.
EU conformity
Johnson Controls, Inc., declares that these products are in compliance with the essential
requirements and other relevant provisions of the EMC Directive and Rohs Directive.
SDP2500 Differential pressure transmitter
1
Issued 19.01.2023 | Rev.2
