afx light HOTBEAM-10R-PACK Bedienungsanleitung Seite 30

Rotating go-
11
bos
12 Gobo rotation
13 *
14 Prism
15 Prism rotation
16 Frost
17 Zoom
18 Fine zoom
19 Focus
20 Fine focus
21 *
22 Strobe
23 Dimmer
24 *
81 - 89 Gobo 9
90 - 97 Shake Gobo 1 ( from slow to fast )
98 - 106 Shake Gobo 2 ( from slow to fast )
107 - 115 Shake Gobo 3 ( from slow to fast )
116 - 124 Shake Gobo 4 ( from slow to fast )
125 - 133 Shake Gobo 5 ( from slow to fast )
134 - 142 Shake Gobo 6 ( from slow to fast )
143 - 151 Shake Gobo 7 ( from slow to fast )
152 - 160 Shake Gobo 8 ( from slow to fast )
161 - 169 Shake Gobo 9 ( from slow to fast )
171 - 179 Gobo 9 no move
180 - 217 Counterclockwise gobo wheel rotate from fast to slow
218 - 255 Clockwise gobo wheel from slow to fast
0 - 127 Manual rotation
128 - 177 Run from slow to fast in counter-clockwise direction
178 - 203 No function
204 - 255 Run from fast to slow in clockwise direction
0 - 255 No function
Prism
0 - 19 No function
20 - 75 6 linear prism
76 - 255 8 facet prism
Prism rotation
0 - 127 Manual rotation
128 - 191 Run from fast to slow in clockwise direction
192 - 194 No function
195 - 255 Run from slow to fast in counter-clockwise direction
Frost
0 - 64 No function
65 - 255 Linear frost
0 - 255 Linear zoom
0 - 255 Fine Zoom
0 - 255 Linear Focus
0 - 255 Fine focus
0 - 255 No function
0 - 31 Strobe open
32 - 63 No Strobe
64 - 95 Strobe from slow to fast
96 - 127 No Strobe
128 - 143 Fast to slow, slow close fast open
144 - 159 Slow to fast, fast open slow close
160 - 191 Strobe open
192 - 223 Random strobe from slow to fast
224 - 255 No strobe
0 - 255 Linear dimmer
No function
