EMPTYING THE DUST BOX
• Empty the dust box when it is full (observation facilitated
by transparent windows) or when vacuuming power is
notably reduced.
• Open the lid of the dust box by pressing the release dust
button to open the lower tank cover (5) and empty the
contents into the appropriate waste disposal receptacle.
(Fig. 3).
• Check the condition of the dust box filter and clean it if
necessary.
CHANGING THE FILTERS
• Dust tank HEPA filter (high-efficiency air filter that
efficiently retains spores, ash, sawdust, pollen, etc.), it is
advisable to change it a least once a year or after every
50 hours of use or if its potency diminishes remarkably.
TO REMOVE THE FILTERS
• Remove the dust tank by pressing the tank removal
button (4) and turning it clockwise, as indicated by the
arrow and the padlocks. (Fig. 4).
• Extract the cyclone by turning clockwise. The filter is
inside the cyclone, and to remove the filter from its
anchor, turn it clockwise, as indicated by the arrow and
the padlocks. (Fig. 5).
• To reassemble the filter, proceed with the above
instructions, in reverse order.
CLEANING THE ROTARY BRUSH
• To remove the brush:
- At the bottom of the shoe, you have to move the tab
towards the open padlock and unhook the side piece
that fixes the brush and releases it. (Fig. 6).
- Remove the brush and clean.
• To reassemble the rotary brush, follow the above
instructions but in reverse.
• To remove the mini turbo brush (included in the Homeland
Digital Animal Flex model):
- Unlock the brush by turning the side lever anti-
clockwise and pulling it out.
- Remove hair, dust, etc., that may have been caught.
• To reassemble the mini brush, follow the above
instructions but in reverse.
SUPPLIES
• Supplies can be acquired from distributors and authorised
establishments (such as filters, etc.) for your appliance
model.
• Always use original supplies designed specifically for your
appliance model.
• The type reference of the battery pack for this appliance
is S7C for model HVCA72590B (Homeland Digital Flex)
and S780(INR18650-25PG) for model HVCA72591B
(Homeland Digital Animal Flex).
HOW TO REPLACE THE BATTERIES
• CAUTION: The appliance must be disconnected from the
mains when inserting/removing the removable batteries.
• CAUTION: Use only the type of battery with the specific
reference for your hoover model.
• Using a different battery may cause an explosion or fire
hazard.
• Remove the battery by pressing the removable battery
button (1).
• Insert the new battery respecting the polarity, and slide it
in until you hear a click.
TO REMOVE THE BATTERIES, ONCE THE LIFE OF THE
APPLIANCE
• Remove the battery by pressing the detachable batteries
button (1).
• Then, dispose of it into special containers. Do not
disassemble or dispose of in fire.
