PRODUCT ASSEMBLY

Before first use, clean all parts and accessories (see "Care and Cleaning" section).
ASSEMBLING THE FOOD GRINDER ATTACHMENT
1
Sharp Side
Insert the Grind Screw into the Main
Housing securely.
Place the Blade over the end of the Grind
Screw.
ASSEMBLING THE FRUIT/VEGETABLE STRAINER ATTACHMENT
1
Secure the smaller spring end of the Shaft
Assembly into the Large Grind Screw.
Insert the Long Grind Screw into the Main
Housing.
3
Notch
Tab
Insert the Collar over the Strainer Cone
and rotate clockwise to secure.
Slide the Strainer Shield over the cone and
latch on the top of ring.
6
W11373931A.indb 6
2
Notch
Place the desired Grinding Plate over the
Blade, matching the notch of the plate
with the tab on the bottom of the Main
Housing.
Place the Collar on the Main Housing,
turning clockwise by hand until secured but
not tightened.
2
Place the Strainer Cone over the Long
Grind Screw matching the notch of the
Strainer Cone with the tab on the bottom
of the Main Housing.
4
Collar
Place Splash Lid on the Strainer Shield.
Tab
Tab
Notch
8/28/2019 8:00:51 PM
