HyperDeck Extreme Control Rear Panel

8
8 Power Inputs
The HyperDeck Extreme Control has inputs for both AC and DC power.
9 USB
A USB port lets you connect your controller to a computer so you can update via the
HyperDeck Setup Utility.
10 Ethernet
The Ethernet connection is not enabled at this time.
11 Reference
Reference out and reference in connections for synchronous recordings between
connected devices.
12 Deck Control
Eight numbered RS-422 connections to connect up to 8 RS-422 enabled devices.
9
10 11 12
HyperDeck Extreme Control Rear Panel 79
