Swim & Fun KRETA XL POOL Bedienungsanleitung Seite 54

UK
Check that the circle is round and correctly placed in rela-
tion to the marking peg used in the base.
It is very important to be certain that the pool liner will
subsequently be correctly positioned (Fig. 2).
2. Assembling the pool wall
This requires a minimum of two adults, preferably more, as it can be quite 'lively' to work with the pool wall at
this point. Therefore, you should never assemble it under windy conditions!
Place the pool wall vertically on a piece of cardboard in the centre of the bottom frame. The wall is rolled out
clockwise and then placed vertically into the bottom rail the entire way around. Remember to check that the
pool wall is not being installed upside-down – the perforated part of the wall must be facing upward (not illus-
trated). The perforations are only important if you later wish to upgrade the pool with a sand filter system and
a built-in skimmer on the pool wall.
NOTE
that the length of both the bottom and top rails must
be adjusted on site for the pool wall. You therefore must saw
off a piece of the bottom rail in order to be able to assemble the
pool wall. Exercise caution. Do not cut a corresponding piece
of the top rail until the pool is finally assembled.
3. Closing the pool wall
You MUST use all supplied screws and bolts. There must be no unused screw holes in
the pool wall. Insert the screws from the inside and tighten them with the washers and
nuts on the outside. Place the plastic caps over the nuts on the outer side of the pool wall.
4. Protection of the liner
On the inside of the pool, the heads of the screws are covered with the ac-
companying blue strip which is taped securely to the wall in order to protect
the pool liner from wear and tear (Fig. 3).
5. Check the work done so far
Check one more time that the base of the pool is completely level
and that the pool wall forms a perfect circle in order to avoid prob-
lems from arising in the subsequent installation of the liner. The
latter can be done by measuring the diameter across the pool. Any
errors must be corrected immediately before continuing with the
assembly.
6. Layer of masonry sand on the inside of the pool (Fig. 4)
A small layer of masonry sand prevents the liner from being forced out under the
pool wall. Therefore, there should be a layer in the space between the ground and
the pool wall the entire way round. Use debris-free masonry sand. Ensure that the
masonry sand layer surface is solid and level the entire way round.
54
Fig. 2
Ground
MV-1930/1931-07-2022 . © Alle rettigheder forbeholdes Swim & Fun A/S
Fig. 3
Liner
Seams
Steel wall
Bottom profile
Masonry
sand
Fig. 4
